Acme Revival connects your Bose SoundDock Portable with a nationwide network of skilled electronics technicians built to fix what manufacturers won't. Start online, ship it in, and track every update and outcome in one transparent Service Dashboard.
1
Repair
$49.00
FLAT-RATE REPAIR (LABOR)
90-Day Warranty
No-Fix Repair Guarantee
Revival’s flat-rate repair service is a best-effort attempt to diagnose and repair the reported issue. The advertised price covers technician labor only and will not increase.
If replacement parts are required, we’ll provide a separate quote for your approval before proceeding. If we can’t complete the repair, your labor charge will be refunded. A separate $25 Repair Network Service Fee applies, along with return shipping & handling. These charges are non-refundable.
Repairs may be limited by device condition, prior damage or modification, safety concerns, or unavailable manufacturer-controlled parts or resources.
Most Recent Repair Requests:
2 (Known) Parts List:
AP_UJLZVG2NWDB2CSA95A2U7H
MODULE ASSY, CRADLE, SVC, MD SLVR, BLK; OEM P/N: 300660-101
AP_NAUYVQSAO1ZHJP9APO269P
MODULE ASSY, CRADLE, SVC, MD SLVR, WHT; OEM P/N: 300660-102
AP_V47GGT7KBFQEUG2S50CLSI
DSP, SVC BOARD, ROHS (Works With iPhone); OEM P/N: 319975-001S
AP_DQLKFT1OKJEF0FVTWU1CU5
DSP, SVC BOARD, ROHS (Works With iPhone); OEM P/N: 319975-011S
AP_96ZLG0SRGN8Z54GEVXJUZG
DSP PCB ASSY, SVC, ROHS; OEM P/N: 307983-021S
AP_FHS9V8GC91EMJ154FWIAAN
DSP PCB ASSY, SVC; OEM P/N: 307983-001
AP_H8EWO012RDLQT2D76UZO2B
DSP PCB ASSY, SVC; OEM P/N: 297427-004
AP_9WMYL3YAFDX084SSS6IP3T
*AMP BOARD, SVC, ROHS; OEM P/N: 346581-001S
AP_NFKIKYBCYX82GAXD8OIDC2
*AMP BOARD, SVC, ROHS; OEM P/N: 307960-002
AP_HU5BWHP1O5IGR2QDIR0QFF
SPS, SVC BOARD, MAX, ROHS; OEM P/N: 346579-001S
AP_UV3Z8NXNLLB7496HD689HN
IO BOARD, PCB ASSY, SVC, ROHS; OEM P/N: 346587-001S
AP_995VO4AZCQCKS3FF3Q8BD4
IO BOARD, PCB ASSY, SVC, ROHS; OEM P/N: 307957-002
AP_G5U1D165PJRJHVEJN5XAC6
DOCK, SVC BOARD; OEM P/N: 346590-001S
AP_Y0FB917L3VZ11W5REZNYGV
DOCK, SVC BOARD; OEM P/N: 307958-002
AP_SU3Y5E8RK1SSLDSN3YZZ7V
DOCK, SVC BOARD; OEM P/N: 307958-001
AP_2TYOX5IX24YUSNOB6Z3LJL
IR, SVC BOARD, ROHS; OEM P/N: 346585-001S
AP_ALACHNHPFIXJ922NWV7B8U
RECHARGE, LI-ION, BATTERY PACK, BLK; OEM P/N: 300769-003
AP_I89FAZHAIYLRMYVH101IYU
RECHARGE, LI-ION, BATTERY PACK, WHT; OEM P/N: 300769-004
AP_K76BSETFN1F2HVI74JSPT4
RECHARGE, LI-ION, BATTERY PACK, BLK; OEM P/N: 043517
AP_ZI1FRXU9ZWBH9PY4X1R26O
RECHARGE, LI-ION, BATTERY PACK, WHT; OEM P/N: 043516
AP_CTBAX5GVYUY4YDQKR3CTQA
PWR PACK, 20V, 1.5A, BLK (circular); OEM P/N: 363120-0101
AP_FLNFLZ6IF2OVM6RP8EGGLR
PWR PACK, 20V, 1.5A, BLK (rectangular); OEM P/N: 301141-001
AP_T8710D8I2FUMO8I4JUW9Q1
PWR PACK, 20V, 1.5A, WHT (rectangular); OEM P/N: 301141-002
AP_YCQFOODYUV4UAPWJ91WJLG
PWR PACK, 20V, 1.5A, BLK (rectangular); OEM P/N: 301141-011
AP_Y110FRCYM9VLN2942JYYZH
PWR PACK, 20V, 1.5A, WHT (rectangular); OEM P/N: 301141-012
AP_53RFDRAFGWZLW82R83H27V
PWR PACK, 20V, 2A, BLK (circular); OEM P/N: 306386-101
AP_X5WNCQXOIS4WPR3NGD7YGK
PWR PACK, 20V, 2A, WHT (circular); OEM P/N: 306386-102
AP_RJZJLDZJOGIVK66MR4LQD0
GRILL, ASSY, MD SLVR, BLK; OEM P/N: 300684-001
AP_FG0IARY8C6TVDKX59CVDUT
GRILL, ASSY, MD SLVR, BLK; OEM P/N: 309981-001
AP_ZNB4560TAH9XNTM4EZZN70
GRILL, ASSY, MD SLVR, WHT; OEM P/N: 300684-002
AP_RDS47UEHUWC2ERMAGEUECE
GRILL, ASSY, MD SLVR, WHT; OEM P/N: 309981-002
AP_PUKVQ87OZMYYI2OQ00W07A
ENCLOSURE, REAR, BLK; OEM P/N: 300693-011
AP_JOWF7U24R5KUSFHKKVVV5P
ENCLOSURE, REAR, BLK; OEM P/N: 300676-011
AP_VMMPPTDQWE6DETSAV2UXRG
ENCLOSURE, REAR, WHT; OEM P/N: 300676-012
AP_SNETORR0NG2U7Y7Z55A6CX
BAFFLE, FRONT, SHEET METAL; OEM P/N: 300696-001
AP_WYEYTA44YFJ868WXF9LWSV
TWIDDLER ASSY W/HARNESS; OEM P/N: 302612-001
AP_EQJM9S4H6H5WA0GXHB11VQ
TWIDDLER ASSY W/HARNESS; OEM P/N: 302612-001
AP_AC9L8KWMVP6DZXFX6UOC5Z
REMOTE CNTRL, IR, 6 FUNC, BLK; OEM P/N: 301373-001
AP_4LSRUOHN5G3FOKXIWCV2RP
REMOTE CNTRL, IR, 6 FUNC, WHT; OEM P/N: 301373-002
AP_TC36S7X9WJO3BCKVI6EEK3
CRADLE ASSY, PTD, MED SLVR, BLK; OEM P/N: 300685-004
AP_Y94S84B8ISVV9EV4PKG8PH
CRADLE ASSY, PTD, MED SLVR, WHT; OEM P/N: 300685-003
AP_VXO963YFY2KBDZYIHPUP0B
RS232 TO TTL CONVERTER, B+B ELECTRONICS MODEL 232LPTTL
AP_730Q8V8386FW0CVNSVPKAZ
IPOD ELIMINATOR PCB; OEM P/N: 287089
AP_KORQAGND4SOVN1KE9GI61T
ETAP CABLE; OEM P/N: 309866-001
AP_L48ZCNRGCBLMEYLYAG6XET
SOUNDDOCK PORTABLE REFLASH SOFTWARE
AP_PM8B9OT0DRRHV0LQNC5K5A
SOUNDDOCK PORTABLE UPDATE FILE
AP_8ND4KOIFM6320FYYIFGFP3
TOP CRADLE, BLK; OEM P/N: 300690-001
AP_8BO3L2JCA3F22YA65NHD6X
TOP CRADLE, WHT; OEM P/N: 300690-002
AP_U4SZT6CZ2HMSA1UQGEBY2E
PLATE, BOTTOM ENCL, BLK; OEM P/N: 305265-001
AP_LYR5J4SI5YWB4ZR2S11I6Y
DOCK, TRIM, METAL, BLK; OEM P/N: 301498-001
AP_RB8V3N542DGK9AVFXN5OR1
DOCK, TRIM, METAL, WHT; OEM P/N: 301498-002
AP_OJPRSDQ6QJZY0KFN9P6JZ2
NUT PLATE, LEFT; OEM P/N: 300679-001
AP_8WG72POHW5SFBJ4301XBP8
NUT PLATE, RIGHT; OEM P/N: 300680-001
AP_NLPT1YWHE86426C2TLM4X0
DAMPER, GEAR, LOW PROFILE; OEM P/N: 305113-001
AP_PXDL2YWEJG8NIIZV04A9EM
PLATE, CRADLE STOP; OEM P/N: 304103-001
AP_W8FLRC67YB2JC6LIFUHST1
LATCH; OEM P/N: 300686-003
AP_NSLVRVKV0Y8AQ919F0GK2D
LATCH; OEM P/N: 300686-001
AP_COQ61SDTIVI6UV4UZDRL4H
SPRING, DOCK; OEM P/N: 301754-001
AP_Y8EM11GXGMPUSTP3C85QMO
SPRING, CRADLE LATCH; OEM P/N: 309584-002
AP_TSEMOKCG2AJD0M76AIYBAH
SPRING, CRADLE LATCH; OEM P/N: 300687
AP_6TNBR1DE5W6NQ578A8VGNG
MAGNET, DOCK; OEM P/N: 304109-001
AP_5F8LTUFUPE5I50EQ5TSNCE
CABLE, 28AWG, RIBBON, 1.0MM, 220MM; OEM P/N: 302209-015220
AP_NI996UJAOZZQS0ANYPRMZM
CABLE, 28AWG, RIBBON, 1.0MM, 220MM; OEM P/N: 302209-15220
AP_5VFKVSKF8562OKXXPJ7TSP
CABLE, FFC, 10POS, 0.5 MMP, 165MM; OEM P/N: 303565-165
AP_RG5XPG9AH20X0T9MGKBCGC
CABLE, FFC, 8POS, 0.5P, 155MM; OEM P/N: 303564-155
AP_4G9HS6UIRMQE6UES62ESJ2
CABLE, FFC, 25POS, 38MM; OEM P/N: 301956-038
AP_KY89S01LF0QE7O7T587A6D
CABLE, FFC, 5POS, 85MM; OEM P/N: 301957-085
AP_KJJUELI05LXZSY3EY6UFI0
CABLE, FLEX, 2POS, 0.5P; OEM P/N: 310678-001
AP_0I9GBWMMVHLVTPANGEU8K8
BATTERY PACK 8-PIN BLADE CONNECTOR INTERFACE
AP_58I9EGXENNR6CHWK6M0GP0
BATTERY PACK SPRING-LOADED COIN SCREW ASSEMBLY
AP_H6UKZBAM9VXYX6RVPMSPSN
30-PIN IPOD DOCK CONNECTOR
AP_YAA8P28JALSGSIVI334LFR
AUX INPUT 3.5MM JACK ASSEMBLY
AP_8YU87M127BSU5V2KTWTURV
POWER INPUT JACK ASSEMBLY
AP_K0CXE9WQLT7OMI38M6OPK1
TOUCH-SENSOR ELECTRODE ASSEMBLY
AP_GXQSC8QYLZ91ED8TNCK5C3
IR RECEIVER WINDOW/LIGHT PIPE
AP_43AMA1KLMW4OFJTZY2OTX3
STATUS LED LIGHT PIPE
AP_JCV2ZHA30YYR5MXZ1S1O9Z
SPEAKER HARNESS, LEFT
AP_20VVTL3FPQKX7VKSKH4BW8
SPEAKER HARNESS, RIGHT
AP_5BYK65434UBT472G25VDUN
ACOUSTIC PORT/HANDLE TRIM
AP_1HWK4X2QFPKNAC4WMWDCLR
BAFFLE-TO-ENCLOSURE ACOUSTIC SEAL
AP_3KDL2SP5ID3GPU54G2XLLV
FOAM, TOP, PORON; OEM P/N: 308109-002
AP_N1VZA16SXHPOPCUNH4G3QQ
FOAM, BOTTOM, PORON; OEM P/N: 308110-002
AP_K5JGCVOQV2TACRC1MC7NJR
PAD, THERMAL; OEM P/N: 303561-001
AP_CR1N0NHAVYQBE75AL2329S
TAPE, FOAM; OEM P/N: 307725-012
AP_MKNWF83L6XFZH2GBJ2FWWX
GRILL GASKET; OEM P/N: 304107-018
AP_RJAN94GG1Y1MKJNAA1HMZ9
GASKET, EMI, RECTANGULAR; OEM P/N: 307375-050
AP_J1FH3VQ7DZ959KZSWJL9TF
ISOLATION GROMMET; OEM P/N: 305269-001
AP_4MLB8E6WKKUCFHJRQQ4407
FOOT, RUBBER; OEM P/N: 301750-001
AP_ANNLYBT8BRLRKN3ZHKTHWQ
INSERT NANO, SD P, BLK; OEM P/N: 307663-001
AP_93Z5LY1ZGWVWT52AQK2UH6
INSERT NANO, SD P, WHT; OEM P/N: 307663-002
AP_8ISLMPH2PB2EXBOSK68H4K
INSERT, UNIVERSAL, BLK; OEM P/N: 303570-001
AP_4UJQ7R9PL7Y8YTSGIH79AG
INSERT, UNIVERSAL, WHT; OEM P/N: 314120-0020
AP_Z8IO5N4ON8F1OY99FXB2RK
UNIVERSAL INSERT, IPOD, WHT; OEM P/N: 303570-002
AP_92OETCNUY746IT9PSGLLKU
UNIVERSAL INSERT, IPOD, BLK; OEM P/N: 303557-001
AP_SHWN8WKSRG7ROIV5F0DR8L
UNIVERSAL INSERT, IPOD, WHT; OEM P/N: 303557-002
AP_PMFL3CIQTU8GN7C5UUER8R
INSERT CLIP; OEM P/N: 303567-001
AP_0KYGCZHHGTZ6W2U30P9YZX
REMOTE BATTERY, CR2032 OR DL2032 3V LITHIUM
AP_KB3AAXL5NEPJ7JL5WG9389
DOOR, REMOTE BATTERY, BLK; OEM P/N: 347812-001S
AP_QDBLZPWMYK394ECPH1KEEK
*AC CLIP KIT, APAC, BLK (rectangular); OEM P/N: 304114-251
AP_FG52KGJ2ZSL9Z8QTRPY73H
*AC CLIP KIT, APAC, BLK (circular); OEM P/N: 304158-351
AP_6ZPG2HYVNOD3JPOV7CCSWJ
*AC CLIP KIT, APAC, WHT (circular); OEM P/N: 304158-352
AP_Q22DTT7P51JYQOE58H3GTD
*AC CLIP KIT, EU/UK, BLK (rectangular); OEM P/N: 304114-121
AP_ZAT6KRYZA3IUEN4SBD6SWU
*AC CLIP KIT, EU/UK, WHT (rectangular); OEM P/N: 304114-122
AP_AOR55ESMEODLIAO1F3J8LS
*AC CLIP KIT, EU/UK, BLK (circular); OEM P/N: 304158-121
AP_A45AY3VJI9EVZXFWEH4SLR
*AC CLIP KIT, EU/UK, WHT (circular); OEM P/N: 304158-122
AP_GE3CX4VECA6BUIV8J9EKUH
AC CLIP, 120V, US, BLK (circular); OEM P/N: 304158-001
AP_7E8PULFVFB52BADJUEXGPF
AC CLIP, 120V, US, WHT (circular); OEM P/N: 304158-002
AP_X8EQ5LAC50ZRS9DHPOXBHS
AC CLIP, 120V, US, BLK (rectangular); OEM P/N: 304114-001
AP_NJSZZV3P19K3HENTAPIVOQ
AC CLIP, 120V, US, WHT (rectangular); OEM P/N: 304114-002
AP_WAWEHRJ8MHAIYBMRIVGQ70
*AC CLIP KIT, APAC, BLK (circular); OEM P/N: 304158-251
AP_0G32D4RE8PW0W4FVOHVQVQ
*AC CLIP KIT, APAC, WHT (circular); OEM P/N: 304158-252
AP_SDFSGH19LS9DH9JFCO8PFU
AC CLIP, CHINA, RECTANGULAR, BLK
AP_NT0L4PVYIJVL0682DYX9HN
AC CLIP, CHINA, RECTANGULAR, WHT
AP_BZH0J41SU9BEU6EMQ7H97N
AC CLIP, CHINA, CIRCULAR, BLK
AP_BFPK95YY7LQYAXKT9PV21B
AC CLIP, CHINA, CIRCULAR, WHT
AP_51Z5J0H5C9RGKK018GE2DS
AC CLIP, AUSTRALIA, RECTANGULAR, BLK
AP_CNXD0TVXQIBIDS6OC8MHQA
AC CLIP, AUSTRALIA, RECTANGULAR, WHT
AP_UOYD0K00DMH35TUL1W06BG
AC CLIP, AUSTRALIA, CIRCULAR, BLK
AP_ZS5KWF3AECQK3WXIDRIWTQ
AC CLIP, AUSTRALIA, CIRCULAR, WHT
AP_FLKM77MAV0QATIFXASL05P
AC CLIP, KOREA, RECTANGULAR, BLK
AP_5UQ1UCVV1ZVAHQ82VMNW2U
AC CLIP, KOREA, RECTANGULAR, WHT
AP_6L6CZBLUPAU2K0U191RNUK
AC CLIP, KOREA, CIRCULAR, BLK
AP_I9TW0P130IMV46DLZQ22BS
AC CLIP, KOREA, CIRCULAR, WHT
AP_BC1AFITLO50PE5362YBC5L
AC CLIP, ARGENTINA, RECTANGULAR, BLK
AP_SJBEW99NPPRB727KMIB0KU
AC CLIP, ARGENTINA, RECTANGULAR, WHT
AP_546JXK1GF25MOLQDD0FAN8
AC CLIP, ARGENTINA, CIRCULAR, BLK
AP_K14AM7M5K0MX2IWT75PTT3
AC CLIP, ARGENTINA, CIRCULAR, WHT
AP_WG3UO4DCJB48DC8ENPUT54
IC, DSP, TMS320DA705, MASKED; OEM P/N: 289857-7051
AP_AQY789PXN638IEZYUIJKSS
IC, FLASH, SERIAL 1Mb, 3.3V, PROG, SVCE; OEM P/N: 374862-001S
AP_M0ZBDZYP35Q7ZG0ZCXZKGU
IC, FLASH, SERIAL, 1Mbit, 3.3V; OEM P/N: 307546-001
AP_CMI6PXXGDQA9Z4NPEACRK9
IC, PWR-AMP, CLASS D, 20W; OEM P/N: 298092-001
AP_GELVR9BYWTW5AQLETCP2J0
IC, SECURITY, APPLE, 2.0B C2; OEM P/N: 309630-002
AP_EH9H5DKA4WOS6NZC3VILUV
IC, HI-PERFORMANCE, CPLD; OEM P/N: 298467-001
AP_H70OADSE55CHOZZXHRHL53
IC, A/D CONV, 96KHz, 24BIT, AK5381; OEM P/N: 299343-001
AP_SMR2AGX0N8YT41OEYOS78J
IC, DAC, 192kHz, 24Bit, 2ch, AK4384; OEM P/N: 299344-001
AP_CYJLF5C47MGBQM0FBZE2EZ
IC, UC, 8-BIT, FLASH BASED, SSOP; OEM P/N: 299197-677ISS
AP_VE84GLLK89ACS8O2P5MOWE
IC, PWM, VOLTAGE CONTROLLER, TPS40200; OEM P/N: 303218-001
AP_MGOKEZI955BUDJP793MVZN
IC, SENSOR, QT, 5V, QFN; OEM P/N: 300674-001
AP_MMEIVDNK8Y4L0VQJDP25J0
IC, MULTIPLEX/DEMULTIPLEX 2-CH; OEM P/N: 298096-003
AP_FPXSZ103ND3U74ZGGICGL1
IC, DUAL BILAT, ANALOG SWITCH; OEM P/N: 299221-001
AP_8YMF2TNG769ZV87LRUN01F
IC, OP-AMP, LO-PWR, 1MHz, SC-70; OEM P/N: 302888-001
AP_I1QRXCQFW07VSV5UG54GMI
IC, V REG, POS, 3.3V, 0.15A, LDO; OEM P/N: 299071-033
AP_OERCSG69ZCF9OTAIPZNT87
IC, VOLT REG, ADJ, 500MA, DPAK; OEM P/N: 258496-001
AP_3NI244PHWGVZ0TXRYKVUK6
IC, VOLT REG, SMD, POS, SOT89, +5V; OEM P/N: 258167-05
AP_17CDYHAI6B1I306HE82JLF
IC, VOLT REG, SMD, POS, SOT89, 3.3V; OEM P/N: 258167-33
AP_SX5K0TMJ5E98SO0P5N9ZE5
IC, RESET, SOT-23, MAX809, 2.63V; OEM P/N: 191158-06
AP_97HI09K44CYOMQ3UNC1ZZE
IC, INVERTER, SMD; OEM P/N: 266582-001
AP_6DWYMSRSYQ96P8LG9MNHWK
TRANSISTOR, MOSFET, P-CH, 30V; OEM P/N: 298094-001
AP_6HBAM06VOIFYF4BJ054LHP
XSISTOR, MFET, P, SOT-23, 40V, 3.0A; OEM P/N: 303215-001
AP_AJ7S89B4FTC67MUB6E91XP
XSISTOR, P, 50V, 2SA1341; OEM P/N: 146818
AP_7BQFLQEBAYCCFE93D2IJJK
XSISTOR, BPLR, P, 40V, 200mA, SOT23; OEM P/N: 148596
AP_OFL5BVFCWRVFLTZHD8Q1ON
XSISTOR, BPLR, N, 40V, 200mA, SOT23; OEM P/N: 146819
AP_YPE0564NL4N663GDOD6W34
XSISTOR, BPLR, N, 50V, 100mA, SOT23; OEM P/N: 146817
AP_YSFPVA33J3WA1IG5DJRY6I
22uH, INDUCTOR, FIXED, 3.9A; OEM P/N: 300618-220M
AP_QHQDL6JQKO3QOFPUKM4SQT
220uH, 1.0A, SMT, 20%; OEM P/N: 303213-221M
AP_XX2Z4GZQG3WMN7BN434MGD
47uH, 1.1A,SMT, 20%; OEM P/N: 303222-470M
AP_ZDCRF3ZMU60MPE1IBH7A2R
330 OHM, BEAD, FERRITE, 0805, 1.5A; OEM P/N: 267539-331
AP_HVDZTD8HXOVBSPPW4B9VNE
330 OHM, FERRITE BD, 0603, 200MA; OEM P/N: 268373-331
AP_1XYE41F8RKOXLRU56E9DH1
BEAD, FERRITE, CHIP, 1806; OEM P/N: 256116-181
AP_NEYJVLJ3DG60QVJV1KDPYY
CONN, DC PWR, JP3.5MM, COMBO; OEM P/N: 301948-001
AP_ZBCYPQIUA6A949XKT43E2L
CONN, BATTERY, 8-PIN, 2.0mm; OEM P/N: 301572-008
AP_FS774DQIX1A9GVCCB4FZAY
CONN, HEADER, 1mm, SMT, 20POS; OEM P/N: 301236-T020
AP_D4RE4VCIFBDJA1U1C197N0
CONN, HEADER, 25-POS, TOP ENTRY, SM; OEM P/N: 253356-T25
AP_BH6C8UPWSA0LP8X4GHOIZ6
CONN, HDR, 6POS, VERT, SMT, ZIFF; OEM P/N: 305369-T06
AP_OKOUOI8579C5ZZ82LA5GXJ
CONN, HEADER, 5-POS, TOP ENTRY,SMD; OEM P/N: 253356-T05
AP_L6351R50RWH41ON22Q4UN1
CONN, SMT, .5MM, 10-POS, FFC; OEM P/N: 269863-010
AP_EN8SMQVZ18V267V93Q6T5E
CONN, SMT, .5MM, 8-POS, FFC; OEM P/N: 269863-008
AP_WNLZNLX1T20TG7W6DPFO7K
CONN, 2.5MM, 2 POS, FORMED; OEM P/N: 307962-001
AP_J4KQKVE3EFYSUK545L7YP9
CONN. ,SMT, LIF, 5 POS., SIDE; OEM P/N: 255130-005
AP_G1CUNV0R32QWFBEP2RPWHS
CRYSTAL, 16.9344MHz, 4-PIN SMD; OEM P/N: 291429-004
AP_DF6W6TOIQDX5HSX036QDQ4
DIODE, SCHOTTKY, 60V, 3A; OEM P/N: 307429-60
AP_IU84A8AB6GJVTUETIYA1C4
DIODE, SCHOTTKY, 40V, 3A, SMB; OEM P/N: 193847-001
AP_0N1KQR391JASGKOBIISORB
DIODE, ZENER, 22V; OEM P/N: 307428-22
AP_M8FDDBYGO2041TWCDN6R7N
DIODE, SHOTTKY, BAT42W, SOD-123; OEM P/N: 196984-002
AP_RQABC4T5N8BO689UV7V91Z
DIODE, SOT-23, BAV 99; OEM P/N: 147239
AP_P0PCO2JX7RHF20A7W1NLJ7
DIODE, SWITCHING, 75V, 200mA; OEM P/N: 148582
AP_2RA7EZPA3LTJ4CA9W6C5LW
DIODE, LED, 625nm, 160mA, 5V; OEM P/N: 307558-001
AP_PNTN33V7UNT87UTK9U9KSU
220uF, EL, SMD, 105, 35V, 20%; OEM P/N: 255071-221V
AP_TSGMMFUIBHVW6VDRKHPHY3
100uF, EL, SMD, 105, 35V, 20%; OEM P/N: 255071-101V
AP_WERIT4S3CYP6VDO9YFNWSX
100uF, 7343, TANT, LO-R, 10%; OEM P/N: 275411-107
AP_0HFA170T0KD9BFC67PXGXM
100uF, EL, 85C, 16V, 20%; OEM P/N: 177902-101C
AP_T1JY16669JSOXISZ6QO5HJ
47uF, 7343, TANT,16V, LO-R, 10%; OEM P/N: 275411-476
AP_12HKAWYU24HFGQINS9UEIV
10uF, EL, 85C, 16V, 20%; OEM P/N: 177902-100C
AP_HRQW9M60WEBUF03YMKALCJ
10uF, EL, SMD, 105C, 35V, 20%; OEM P/N: 255071-100V
AP_KS8R9IS7KG281HCQGSHFMP
2.2uF, 1411, TANT, 25V, 20%; OEM P/N: 188588-225
AP_9QTT1DPDE1J3R7WCCU0JGU
1uF, EL, SMD, 105C, 50V, 20%; OEM P/N: 255071-1R0H
AP_PWUVO7253HPDI8FLSZZY90
1uF, EL, 85C, 50V, 20%; OEM P/N: 177902-010H
AP_MV7LUL8DWYMTECQWZCA5CZ
0.47uF, 10V, X5R, 0603; OEM P/N: 278992-474
AP_LD1E91A8CYGQ4IC6QVP06Y
.22uF, 0805, X7R, 25V,10%; OEM P/N: 181264-224
AP_BS9I435TV7W7Y1J5OHUWDZ
.1uF, 0805, X7R, 50V, 10%; OEM P/N: 286499-104
AP_PF4FCQ8YC91X0WTSPE2YEK
0.1uF, X7R, 0603, 50V, 10%; OEM P/N: 191470-104
AP_04583WYEMG8IVKEMSR0COY
.033uF, 0603, X7R, 50V, 10%; OEM P/N: 191470-333
AP_FI925JMXV26VD7KNN5J5F3
33000pF, X7R SMD, 0603, 25V, .1%; OEM P/N: 257154-333K25
AP_E92ITG11WAUPL3HBQ77E6R
.01uF, 0805, X7R, 50V, 10%; OEM P/N: 286499-103
AP_A37TOWTLY8OE7VIQYKEDVT
.01uF, 0603, X7R, 50V, 10%; OEM P/N: 191470-103
AP_NNI7E65Y4U41UDWZPCCADO
.0082uF, 0603, X7R, 50V, 10%; OEM P/N: 191470-822
AP_VTJ49Q6BXIUXPSIU2NIU2D
3300pF, 0805, X7R, 50V, 10%; OEM P/N: 286499-332
AP_7O37T34I4KLLRBQ1ZRWHVD
3300pF, 0603, X7R, 50V, .1%; OEM P/N: 191470-332
AP_6M5SKO955NLW7TGOPY9JGT
1800pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-182
AP_A6D7AUSQ041BULO0E5A0OU
1000pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-102
AP_W4907SHJ1BS0EILP49VM5K
470pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-471
AP_A0XUTL985AMVP9K8HTL4TA
330pF, 0805, COG, 50V, 5%; OEM P/N: 133622-331
AP_MXLYTS16LAEJB4JPKQ43TL
330pF, 0603, X7R, 50V; OEM P/N: 191470-331
AP_VY75K91VUJI3UB2K054GI0
220pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-221
AP_4ZIA6EMC9EAWFMI7QFK0HN
180pF, 0603, COG, 50V, .1%; OEM P/N: 188454-181
AP_MZ7NWRFLQEF8KSGAG3VU52
100pF, 0805, COG, 50V, 5%; OEM P/N: 133622-101
AP_UHU99AVWMGSU1E1RT44KMR
100pF, 0603, X7R, 50V, .1%; OEM P/N: 191470-101
AP_DMO8K2BC6PIZAEVQO65MKV
8pF, 0603, COG, 50V, .1%; OEM P/N: 188454-8R0
AP_0E7YR2HFDI7SMFOVMLWVFQ
5pF, 0603, COG, 50V, .1%; OEM P/N: 188454-5R0
AP_P1UVYFJB6ECF23ET867T23
0.10 OHM, 0805, 1/8W, 5%; OEM P/N: 304926-R10
AP_T089LEHTOEDAQHFB2YLWIO
301K, 0603, .1W, 1%; OEM P/N: 191465-3013
AP_BL78QVZVH83SG8WZES0VTU
200K, 0603, .1W, 1%; OEM P/N: 191465-2003
AP_ALPHOV85NKZSP9J469FD3A
121K, 0603, .1W, 1%; OEM P/N: 191465-1213
AP_502FLJ6Y2TRA984LJ1F5X1
100K, 0603, .1W, 1%; OEM P/N: 191465-1003
AP_0F20PCW76NOFAXNDAEMD6X
60.4K, 0603, .1W, 1%; OEM P/N: 191465-6042
AP_1BJA23AE7D2G3C1X34SKNQ
49.9K, 0603, .1W, 1%; OEM P/N: 191465-4992
AP_MUAKBPPFBDBIBGAO1MRKRC
39K, 0603, SMD, .1W, 5%; OEM P/N: 199403-393
AP_S2X06BOG3RSXQKGD2HKZPJ
30.1K, 0603, .1W, 1%; OEM P/N: 191465-3012
AP_EU1E3HW0OFBDTHRE8D6LPD
30K, 0603, .1W, 5%; OEM P/N: 199403-303
AP_RNEGVGW60TNK8VQVX4NTLQ
22K, 0603, .1W, 5%; OEM P/N: 199403-223
AP_5WO7B2WXKLHK8VQ4J2QZIZ
18.2K, 0603, .1W, 1%; OEM P/N: 191465-1822
AP_04UT0WSV4FAX3LGNPWHR54
15K, 0805, .1W, 1%; OEM P/N: 133625-1502
AP_XK0NTHN0XMBFBDUGZAY7TX
12K, 0603, .1W, 5%; OEM P/N: 199403-123
AP_TDR2AHCJ4Y95HA0J5PWZBA
10K, ARRAY, SMT, 4 POS, 5%; OEM P/N: 186433-1034
AP_3VEC6IHYL30MVX7PZCR4DK
10K, 0603, .1W, 1%; OEM P/N: 191465-1002
AP_0IKFUWH1405Y6PMFNC8J85
9.53K, 0603, .1W, 1%; OEM P/N: 191465-9531
AP_HW08NY7MVS0RTMY6O1XM3E
6.19K, 0603, .1W, 1%; OEM P/N: 191465-6191
AP_ZV0VC4DFS63HRGT9JYR900
3.9K, 0603, .1W, 1%; OEM P/N: 191465-3901
AP_G0ZR78RJ1V639LPNCHY23L
3.01K, 0603, .1W, 1%; OEM P/N: 191465-3011
AP_ZKSU5NR4MPY2S3GFOBHYGG
2.2K, 0603, .1W, 5%; OEM P/N: 199403-222
AP_3XY5UPAJRDKZJ0K1GC71PF
2.0K, 0603, .1W, 5%; OEM P/N: 199403-202
AP_346HCVDWSG3RLWCTE2KLY4
2K, 0603, .1W, 1%; OEM P/N: 191465-2001
AP_UNBKUDZYAY4645WOFQOV4B
1.82K, 0603, .1W, 1%; OEM P/N: 191465-1821
AP_C50CZ626F4UGDDWEJOI0OL
1.33K, 0603, 100MW, 1%; OEM P/N: 191465-1331
AP_TP04OR9YI5WUEVCAF6O3QT
1K, 0603, .1W, 1%; OEM P/N: 191465-1001
AP_QV2RX4LN5R0E55RO13D7SV
1K, 0603, .1W, 5%; OEM P/N: 199403-102
AP_LW3VILPFT3PEQEYNVSEIQY
1M, 0603, .1W, 5%; OEM P/N: 199403-105
AP_M5XQ5PYB4WMIEQVQ48OFQN
330 OHM, 0603, .1W, 5%; OEM P/N: 199403-331
AP_IPP3NTN2ICI0LGWKEKD976
150 OHM, 0603, .1W, 1%; OEM P/N: 191465-1500
AP_1NHOY8CFK6U8ZQIVZLXLOH
100 OHM, ARRAY, SMT, 4 POS, 5%; OEM P/N: 186433-1014
AP_94EI87FHKFLIVN6L41X1AV
100 OHM, 0805, .1W, 5%; OEM P/N: 133626-1015
AP_KXI6797MN1ED2P30YQ5I8W
100 OHM, 0603, .1W, 5%; OEM P/N: 199403-101
AP_W4BLX46TLP0B07KHSN0C36
10 OHM, 0603, .1W, 5%; OEM P/N: 199403-100
AP_CAK4BM8LZ8WGJZMIZK3VJV
SCREW-6-32-PAN_HD-ROLOK; OEM P/N: 306601-001
AP_KIG5PSZVED36N25IC1ZXRC
SCREW, THD FRM, 2-28 X 1/4, PAN; OEM P/N: 289396-004
AP_YYI8TIKXBFRI8Q5SWGKOEQ
SCREW, 6-13 X .625, PAN, XREC/SQ; OEM P/N: 288374-010
AP_VYPBVR8G1R17DN3RB87ITP
SCREW, 6-13 X .5/8 LG HD XREC/SQ; OEM P/N: 288374-006
AP_WRVIFO1L3K91QF462URXDW
SCREW, 6-13 X 5/8 LG HD XREC/SQ; OEM P/N: 307354-010
AP_WS52IWCJ4O7FST2T4O8T4K
SCREW, TAPP, 6-32 x .375, PAN, TORX
AP_DJODQJPDL09DT14PQ4W14L
FASTENER, INTERLOCK, 100mm (velcro); OEM P/N: 309014-100
AP_ECHFJC0L8WW67WEK6BWREP
FASTENER, INTERLOCK, 120mm (velcro); OEM P/N: 309014-120
AP_NBDAK2DVE1LK3W1ZBV6D92
FASTENER, INTERLOCK, 25mm (velcro); OEM P/N: 309014-025
AP_S19FI4XIWM7EFS2ZN7VTIN
LOGO, NAMEPLATE, CURVED; OEM P/N: 301757-001
AP_JTSB565BTQ1FXBDD7NTQ4P
PRODUCT MODEL/BRAND LABEL
AP_V7CFLPACXTV6BM1P4APZ25
SERIAL NUMBER/BARCODE LABEL
AP_L3IPCBBGX064UO0HHLF12F
REGULATORY/SAFETY RATING LABEL
AP_6Z6OLHCT6VR2ADPLAG7MRJ
BATTERY SAFETY/WARNING LABEL
AP_63GQKD2ZUSKVRR7FGN5HGK
ESD PROTECTIVE BAG, SERVICE PCB
AP_AH8H7FXH63231BCQTUU5NE
POLY BAG, ACCESSORIES
AP_RURCPIPGOUS5JZPAD9ABN8
PACKING, TRAY, TOP 14 X 9 X 4; OEM P/N: 300698
AP_UEYS8UCS3OYTP6L4DG52FR
PACKING, TRAY, BOTTOM 14 X 9 X 4; OEM P/N: 300699
AP_MU6T8TSI88NN1JYAVAX2JQ
CARTON, BLK 14.19 X 9.19 X 8, PRINTED; OEM P/N: 311574
AP_TJLWUKN39DB6SIAY4K4PZB
CARTON, BLK 14.19 X 9.19 X 8, BLANK; OEM P/N: 300697
AP_D2BPTAP8Y2R0TM5LHE62LO
SHEET, USER INFO, SD PORTABLE; OEM P/N: 346225-0010
AP_6XXDLL7DQRIR18I2FAUWAA
OWNERS GUIDE, MAX, 8L, US/EU/UK; OEM P/N: 300673
AP_8WEPKQAXYUOYA37QKJK2IH
OWNERS GUIDE, SD P, 6L, AP; OEM P/N: 306331
AP_ZTHK0ZUT0WKDXTZKQNEKI5
SOUNDDOCK PORTABLE SERVICE MANUAL; OEM P/N: 300657-SM
AP_S55MYB7MQLSBGYHSENGVHA
QUICK SETUP GUIDE
AP_F7FJB0F0FELM92KDYEDM7O
WARRANTY/REGISTRATION DOCUMENT
AP_W18I1796AL06DF136ISTYI
PACKING POLY BAG, MAIN PRODUCT
AP_BGJJQRJX7D4YDY1KUX09OW
PROTECTIVE CARTON SLEEVE/INSERT
AP_Y40YXSXQUIMIAMYEHBJA0D
ADHESIVE TAPE, PACKAGING
Repair, service & parts, for your Bose SoundDock Portable
- 1 Repairs are performed on a best-effort basis. Acme Revival utilizes a network of sophisticated technicians and engineers with diverse service offerings; despite this, factors that influence the repair outcome may ultimately prove unsuccessful. Acme Revival makes no claim that it can, guarantee a repair before your device is sent in for diagnostic evaluation; even then, repair and diagnostic work are not mutually exclusive. Despite well-intentioned quoting, repairs may still prove unsuccessful.
- 2 Parts known to Acme Revival via Acme’s Neural Network and documented discovery. These parts may not represent OEM cataloging nor does Acme Revival guarantee display accuracy. Always check with Acme’s Help Desk to ensure availability and accuracy. Parts may not be in new condition, may be unavailable, discontinued, or not offered for independent sale.
