Acme Revival connects your Bose CineMate Series II with a nationwide network of skilled electronics technicians built to fix what manufacturers won't. Start online, ship it in, and track every update and outcome in one transparent Service Dashboard.
1
Repair
$79.00
FLAT-RATE REPAIR (LABOR)
90-Day Warranty
No-Fix Repair Guarantee
Revival’s flat-rate repair service is a best-effort attempt to diagnose and repair the reported issue. The advertised price covers technician labor only and will not increase.
If replacement parts are required, we’ll provide a separate quote for your approval before proceeding. If we can’t complete the repair, your labor charge will be refunded. A separate $25 Repair Network Service Fee applies, along with return shipping & handling. These charges are non-refundable.
Repairs may be limited by device condition, prior damage or modification, safety concerns, or unavailable manufacturer-controlled parts or resources.
Most Recent Repair Requests:
2 (Known) Parts List:
AP_QHCW6DY8CRYZN4NM3E687C
ASSY, BASS MODULE, 120-240V, CINEMATE II; OEM P/N: 362020-110S
AP_R1E9KHRCEK9HIHPRH8IGRL
ASSY, BASS MODULE, 100V, CINEMATE II; OEM P/N: 362020-310S
AP_MOAEIR3WE9MU3IC5LEJI6H
ARRAY ASSY, BLK, CINEMATE, GEMSTONE; OEM P/N: 320560-0010
AP_76Z0BVEJU7O992H8IVLR6U
ARRAY ASSY, BLK, CINEMATE; OEM P/N: 255198-103
AP_DQ73LDPQX3PPGQXGNP7G4Z
INTERFACE MODULE ASSY, CINEMATE SERIES II
AP_5H5CLOSSZUS5DZHRBBYR8Y
CINEMATE II, DSP, SERVICE BOM; OEM P/N: 318878-011S
AP_KK1HINLTC1BVC38JGKKNLZ
CINEMATE II, PS, SERVICE BOM; OEM P/N: 361720-001S
AP_SMHS0J2EZA7ZM0G1GEBSG7
CINEMATE II, IO, SERVICE BOM; OEM P/N: 361719-001S
AP_16PUX4NYNRZ1RV222EBOCQ
CINEMATE II, IO, SERVICE BOM, PREVIOUS REVISION; OEM P/N: 361436-001S
AP_1NJXVBSX502GTL6GMP4B5K
CINEMATE II, IO, SERVICE BOM, OBSOLETE; OEM P/N: 318892-001S
AP_XAEYBBL4IRZLWLZ8S3WMFM
REMOTE, CINEMATE II (PREMIUM); OEM P/N: 323075-1100
AP_164VRPV8JD1K5FU420UYNG
REMOTE, CINEMATE II EURO (PREMIUM); OEM P/N: 323075-1200
AP_L2S0IA35M1EDMCYEURXPDQ
REMOTE, IR, CINEMATE, 1SR, BLK (PREMIUM); OEM P/N: 342835-1210
AP_1DTC9R2PAZJG096V1LHXS0
REMOTE, CINEMATE II (BASIC); OEM P/N: 323715-0010
AP_L9W3Q7XY4J8YEORZSSF0E2
TWIDDLER DRIVER ASSY, 50MM; OEM P/N: 291636-001
AP_UXMAXZNXBJNZ2IKR96IUDW
WOOFER DRIVER ASSY, BASS MODULE
AP_TDF9FPMVJJ7JSQU9IND2D1
POWER SUPPLY TRANSFORMER, PWR, EER BOBBIN, 40AWG; OEM P/N: 322253-0003
AP_SAS6X30EM0Q7VAJ8TK2ELF
IC, DSP, QFP208, ADSP21065LKS_264; OEM P/N: 254191-003
AP_HSZ9BASZ19336BN5752PM7
IC, CODEC, 24-BIT, CS4228A-KS, TS; OEM P/N: 254192-003
AP_PSREN4CTAA6LZRKMKAUL3B
IC, RCVR, DIG AUD, CS8415A, TSSOP; OEM P/N: 267616-002
AP_9E13EFLNG8U79LLUHN8BM6
IC, SDRAM, 64MBIT, 2MX32, 3.3V; OEM P/N: 254182-010
AP_ZMC3LQL59OOXYC4B8VA0KD
IC, PROM, FLASH, 4MBIT (not programmed); OEM P/N: 260332-002
AP_LHJHNNJPOZS2PD5LWCTZJI
IC, PWR AMP, PSO-20, TDA8566TH; OEM P/N: 257975
AP_O75BL4QCWM74Q0P8OJQFIB
IC, PWM CONTROLLER, 80% DUTY CY; OEM P/N: 317119-001
AP_THWJESLQVU9YGUZHZP382W
IC, HALF-BRIDGE GATE DRIVER; OEM P/N: 317085-001
AP_CKT2UNQKNDGO8D7VQ51IHE
IC, PWM, V, CNTRLLR, TPS40200; OEM P/N: 303218-001
AP_BWNHMGRFXSCGVD70TBMRCZ
IC, VOLT REG, ADJ, 500MA, DPAK; OEM P/N: 258496-001
AP_BNB5P7DI22NR7UMCBIY2VS
IC, VREF, SHUNT, ADJ, 1.24V, SOT23-3; OEM P/N: 322217-001
AP_NLVBWJHYUPQV2WDIEOKQ74
IC, RESET, 3.3V, SOT23, 5-PIN; OEM P/N: 256123-001
AP_3MD6N2QFWW1PY1T9ALPZ7I
IC, INVERTER, 5V, 74VCHU04; OEM P/N: 258464-004
AP_IAPPZI143J6BB8YHAGUXED
IC, OPTOISOLATOR, CNY17F-1X007; OEM P/N: 254120-002
AP_AWZJM7FR6DTNY04D8KEGY3
ENCLOSURE, REAR, PAINTED, BLK; OEM P/N: 318960-403
AP_VMB2MZQHL6PUXDUDWE6GPX
BASS MODULE CABINET ASSY
AP_PCO5ZYGYZOVGVAGOX6E25H
BASS MODULE PORT DUCT ASSY
AP_LIFKANBZ1KETDR9VEEPCCD
INTERFACE MODULE PCB ASSY
AP_XPYTIWU18QEXN2KCHYEGHQ
INTERFACE MODULE IR RECEIVER ASSY
AP_3EFICUED7Z1KPMJPHAEGD3
INTERFACE MODULE STATUS LED ASSY
AP_EY3FJSRR5RYLZTBUAOS26B
INTERFACE MODULE TOP HOUSING
AP_YUTI1NRFBHDA2AFLRT0TX9
INTERFACE MODULE BASE HOUSING
AP_15GJS3GOMI13IKGBYMBZPI
CABLE, INTERFACE MODULE, BLK; OEM P/N: 318638-1030
AP_OSVYU0TW5L0SE1GD2ZINH8
CABLE, INTERFACE MODULE, BLK; OEM P/N: 318638-101
AP_M4G1ZYLCA9C1LP7H959SWL
CABLE, GS, ARRAY, 9PIN, BLK; OEM P/N: 269984-004
AP_LGSVQE8IBAH80T9IHYR9T8
CABLE, ARRAY, 9PIN, BLK; OEM P/N: 255123-003
AP_2XT4D353NTVR1S16SMLDO9
CABLE, OPTICAL, 2 METER; OEM P/N: 288629-002
AP_5DLJEHH48VF5F4B4CV89FU
CABLE, OPTICAL, 2 METER; OEM P/N: 347411-0010
AP_YXKXZHP6FBJQPO7L3NF3KU
CABLE ASSY, PRIMARY, PWR SUPPLY; OEM P/N: 319486-1020
AP_7GS9OQRYXWXVMTWL26DJNJ
CABLE ASSY, PRIMARY, PWR SUPPLY, PREVIOUS REVISION; OEM P/N: 319486-0010
AP_QWZNT4ZL6Z09G8JBAE9ZGU
CABLE ASSY, SECONDARY PWR SUPPLY; OEM P/N: 319494-0010
AP_O22SKI1Y061IJMR3IE3SE5
CABLE, ARRAY, 10 CONDUCTOR; OEM P/N: 271561-0190
AP_6Q1BTFH89RWBFO1U71Q55D
CABLE, 10 PIN, DSP TO I/O; OEM P/N: 275179-0190
AP_P6XD02VNBVFYOZOFPW1G5F
CABLE, 10 PIN, DSP TO I/O, PREVIOUS REVISION; OEM P/N: 275179-190
AP_GMTGWTKCV1INTD3DKY62XW
CABLE, I/O, DIGITAL; OEM P/N: 322528-001
AP_RD1M8E19DF97HTR8DS6JN4
CABLE, RCA, 6 FT; OEM P/N: 185931-101
AP_JICUYNIQNYHOU1NPNIPAQD
ADAPTER, SCART; OEM P/N: 266221-001
AP_EVL3HQ19PNB236G2HEWF9J
LINE CORD, 120V, POL, DET, BLK, 96"; OEM P/N: 260082-001
AP_Q35GOLYFDUA8VQQRH8V8IV
LINE CORD, 120V, POL, DET, BLK, 60"; OEM P/N: 262814-0310
AP_THDTT50B78CC29A16PZ3T3
LINE CORD, 230V, UKS, DET, BLK, 96"; OEM P/N: 280138-001
AP_99VNSW1SCEXURAMMNPTJRC
LINE CORD, 230V, UKS, DET, BLK, 60"; OEM P/N: 280138-0310
AP_9RKW9KNG55NKW8J1TGPD0S
LINE CORD, EURO, DETACHABLE, 96"; OEM P/N: 148203
AP_ECB3QJLRGUF2MDX2CLO9KR
LINE CORD, EURO, DETACHABLE, 60"; OEM P/N: 280135-0310
AP_HU19AALXEUVRLUQOD9PXUV
LINE CORD, 240V, AUS, DET, BLK, 96"; OEM P/N: 284243-001
AP_FYN9GO6YK5M5M18JB3D00R
LINE CORD, 240V, AUS, DET, BLK, 60"; OEM P/N: 284243-0310
AP_PFQ20BMXYMQL7ICEDUZWRY
LINE CORD, 100V, JP, POL, DET, BLK, 96"; OEM P/N: 260086-001
AP_YUFGV2690BT3X5TRDXMX49
LINE CORD, 100V, JP, POL, DET, BLK, 60"; OEM P/N: 280136-0310
AP_9RSRZ4NVR64A8GQVHBC8HR
GRILLE, ARRAY, BLK; OEM P/N: 302256-004
AP_4WCN3ECPBTQLY4YA4UYN97
GRILLE, ASSEMBLY; OEM P/N: 323211-0010
AP_ZBU4ZBZ66RFL5FDXR0FF7C
SHIELD, POWER SUPPLY; OEM P/N: 319739-0010
AP_7NOR8OCVC3O2NUN2CITNSD
BRACKET, POWER SUPPLY; OEM P/N: 319738-0010
AP_66SZM130GRVSXFKQA8GMWI
BRACKET, HEATSINK,SNAP; OEM P/N: 304144-001
AP_8PG4NFB3WAELVJU8WEG2KF
BRACKET, PCB; OEM P/N: 267182-001
AP_JHP5ZMGCDGMUWO3R4X6X8Q
BRACKET, COVER, BASS MODULE; OEM P/N: 255179
AP_FRH38MT7AKRWUA0OEODNGZ
GRILLE, VENT, AMP, BLK,KAISER; OEM P/N: 255178-203
AP_6B4R4JK30TIMPSXT1ZALSS
KNOB, VOLUME CONTROL, BLACK; OEM P/N: 318324-001
AP_6T9975KZFL17AFI9OYPWO2
CLIP, SPRING, KNOB; OEM P/N: 262542
AP_IESAHH55SR1FWEW38J5Y39
CHOKE, 3.30mH, 1.2A, 250V; OEM P/N: 321518-001
AP_YR6495VRA1RVFCH3Z39U0W
TRANSISTOR, MFET, N-CH, 600V; OEM P/N: 310519-001
AP_EFYV13IAX20LEQEFJQSGKR
TRANSISTOR, TO-92AP, PWR, NPN, 500V,1.5A; OEM P/N: 320835-002
AP_42ZDQXWNOYQHIVO1TARHLY
TRANSISTOR, MFET, P, 40V, 3.0A, SOT-23; OEM P/N: 303215-001
AP_VJAGW23T8WTS7KP56TXDXU
TRANSISTOR, SOT-23, N, MFET, 2.5V; OEM P/N: 252043
AP_GR3JU95YYYL0S864UWU2P1
TRANSISTOR, BPLR, PNP, 500MA, SOT23; OEM P/N: 189290-001
AP_J8DTHDPLG69Y9QZSDP7WUM
TRANSISTOR, BPLR, N, 50V, 100mA, SOT23; OEM P/N: 146817
AP_JMP82XD53W21ORUFV0H5QX
TRANSISTOR, SOT23, BPLR, N, 40V, 200mA; OEM P/N: 146819
AP_KPZ2PPJRQ2GGJYKAGTZP2G
FET, P-CHANNEL, BSS84; OEM P/N: 269693
AP_YWK9XHGH2MIKMB0IEPJST5
DIODE, BRIDGE, RECT, 3A, 600V; OEM P/N: 311102-0600
AP_EBJ0ZX6MRH257I5JZ2RR39
DIODE, PWR SCHOTTKY, D2PAK, 8A, 100V; OEM P/N: 319763-100
AP_WLIYRJXF4NFJ90WCLV0CWZ
DIODE, RECT, FAST, 600V, 1A; OEM P/N: 317066-600
AP_FIY4OZA1W7VRHO5QUTBITA
TVS, UNI-DIR, SMCJ130A, 1500W, 130V, 200A; OEM P/N: 320498-1300
AP_5FQTGI3PXPOJ5PK8SWVVAY
DIODE, SCHOTTKY, 40V, 3A, SMB; OEM P/N: 193847-001
AP_QZK5HIORWK3BNMO6SPHOE7
DIODE, SWITCHING, SOD123, 1N4148W; OEM P/N: 257662
AP_0TZ8PGSB3DGIAX5HOEIPOP
DIODE, SCHTKY, SC70, 30V, SERIES; OEM P/N: 268381-004
AP_DZUDKT6BTNI3M9YC209Z0U
DIODE, ZENER, SMT, IN5262, 51V; OEM P/N: 174265-5262
AP_ZUNBH7BD8BZUZ5RHZATKMA
DIODE, ZEN, SOT-23, 15V, 225MW, 5%; OEM P/N: 135247-5245
AP_A86RWJUJZMAFGGFS0Z0H6U
DIODE, ZEN, SOT-23 5.1V, 225MW, 5%; OEM P/N: 135247-5231
AP_2KNMO9852H4UWIKHOBC01N
DIODE, SOT-23, BAV 99; OEM P/N: 147239
AP_HACFPNEICF8VQVDN3062ME
VARISTOR, bMET OX, 14mm DISC, 300V, 125J; OEM P/N: 361431-0020
AP_Z1GZ92E8VX2M2BER4XKRJA
FUSE, TIME LAG, 4A, 250V; OEM P/N: 310538-4000A
AP_TF3FIRKU5OSY2X83IZH8YN
CAPACITOR, 100uF, EL, 105C, 450V, SNAP-IN, 20%; OEM P/N: 261614-101WB3
AP_OK4XN7T20MYKA5IB1PM0GF
CAPACITOR, 1000uF, EL,105C, 25V, 10MM DIA CUT, 20%; OEM P/N: 196991-102E6P50
AP_9LS08W7E69120XINVMAWSV
CAPACITOR, .01F, EL, 105C, SNP, 25V, 20%; OEM P/N: 269823-103EZ
AP_3BIMW0C3ODGOX4MENV9VW8
CAPACITOR, 100uF, EL, SMD, 105C, 35V, 20%; OEM P/N: 306245-101EE
AP_YPEV45BG2ZD3IRVAZ8BQSF
CAPACITOR, 100uF, 7343, TANT, LO-R, 10V, 10%; OEM P/N: 275411-107
AP_UKBRW41PTD1GS2GBDRVFJQ
CAPACITOR, 0.33uF, FILM, X2, 305VAC, 15MM, 20%; OEM P/N: 310415-334ME
AP_BP1WIUSB1WVPKZQGHWKHSQ
CAPACITOR, 0.1uF, FILM, X2, 275VAC, 10MM, 20%; OEM P/N: 268166-104A
AP_5K9CVLGGMPADR6XQFW3P8S
CAPACITOR, 1000pF, CER, Y1, 250VAC, 10MM, 20%; OEM P/N: 310461-102MB
AP_6CO6RT25CWBYJ4FK9TQYFD
CAPACITOR, 470pF, CER, Y1, 250VAC, 10MM, 20%; OEM P/N: 310461-471KB
AP_1EV3WYJVB1IOO1GVAGSQF7
CAPACITOR, 100uF, EL, 85C, 25V, 20%; OEM P/N: 177902-101EB
AP_2TP0BYQO005BPQMVT450DN
CAPACITOR, 22uF, EL, 85C, 35V, 20%; OEM P/N: 177902-220V
AP_DLHNC2RGYMUZ0QKOJWJ4I7
CAPACITOR, 10uF, EL, 85C, 16V, 20%; OEM P/N: 177902-100C
AP_G8SD5ITRFWJE1JOAXLAQ3U
CAPACITOR, 4.7uF, EL, 85C, 35V, 20%; OEM P/N: 177902-4R7V
AP_K7GTRZKGF960YQJBX3D7J4
CAPACITOR, 2.2uF, EL, 85C, 50V, 20%; OEM P/N: 177902-2R2H
AP_AZAWAGXP4HJGUKU1Y399SX
CAPACITOR, 1uF, EL, 85C, 50V, 20%; OEM P/N: 177902-010H
AP_GARD0PFVPQHRVNIHBIAFQC
CAPACITOR, 1uF, X7R, 0805, 16V, 10%; OEM P/N: 273596-105
AP_HDVNP1E67BP796J29TD7JJ
CAPACITOR, 0.22uF, 0805, X7R, 50V, 10%; OEM P/N: 286499-224
AP_G10CE4QPJJJ10W2WYSVF3O
CAPACITOR, 0.1uF, 0805, X7R, 50V, 10%; OEM P/N: 286499-104
AP_19KOWM70YB0UV40CU02YYZ
CAPACITOR, 0.1uF, X7R, 0603, 50V, 10%; OEM P/N: 191470-104
AP_8ABVV52DSXGF4GKONXZNW9
CAPACITOR, .047uF, 0805, X7R, 50V, 10%; OEM P/N: 286499-473
AP_W7AIX99KJISFTAHZ2GOYUS
CAPACITOR, .047uF, 0603, X7R, 50V, 10%; OEM P/N: 191470-473
AP_ICUK8MHRST0F1HFZLNSO8P
CAPACITOR, .047uF, 0603, X7R, 25V, 5%; OEM P/N: 196999-473
AP_ZXVGQGSB1RUP7D1CCEM50Q
CAPACITOR, .01uF, X7R, 0603, 50V, 10%; OEM P/N: 304991-104
AP_M63FE4JUSQJS7ES5UBC2O7
CAPACITOR, .01uF, 0603, X7R, 50V, 10%; OEM P/N: 191470-103
AP_7NOLVH5DAPA3NK6JS3K05Y
CAPACITOR, 4700pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-472
AP_80I4R2MGJPBMNOSVY5U7CY
CAPACITOR, 3300pF, 0805, X7R, 50V, 10%; OEM P/N: 286499-332
AP_5KTDOZUH019KPWGGMIOREC
CAPACITOR, 3300pF, 0603, X7R, 50V; OEM P/N: 191470-332
AP_A57H79QWABPJHKVCQSVCBC
CAPACITOR, 2200pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-222
AP_8LXLUORDDPD0I6Z1NSW875
CAPACITOR, 1000pF, 0805, COG, 50V, 5%; OEM P/N: 133622-102
AP_LQ7VK5EVWF907AWV6O7OF0
CAPACITOR, 1000pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-102
AP_5DXYTFMJUFZBV9U1ADYFDT
CAPACITOR, 1000pF, 0603, COG, 50V, 5%; OEM P/N: 188454-102
AP_8WO50SBW2RNCQ9GD53FKGG
CAPACITOR, 470pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-471
AP_S99TQO6PRMQDYEVSM2C28I
CAPACITOR, 470pF, 0603, COG, 50V, 5%; OEM P/N: 188454-471
AP_F0Z4DUNN4OF8B3A607ZROJ
CAPACITOR, 330pF, 0805, COG, 200V MIN, 5%; OEM P/N: 260668-331J
AP_A11QZR7YJ3O5RI1YLSNST8
CAPACITOR, 150pF, 0603, COG, 50V, 5%; OEM P/N: 188454-151
AP_3NIB26ND9T89J2FC2IFEEJ
CAPACITOR, 100pF, 0603, X7R, 50V, 10%; OEM P/N: 191470-101
AP_HEUMJA8UEKNSGZMQ7E92UI
CAPACITOR, 100pF, 0603, COG, 50V, 5%; OEM P/N: 188454-101
AP_8PVEH1EIGS5DG1V31FO5K0
CAPACITOR, 68pF, 0603, COG, 50V, 5%; OEM P/N: 188454-680
AP_P9SNGPRV32C1Z1T2YQDDE7
CAPACITOR, 47pF, 0603, COG, 50V, 5%; OEM P/N: 188454-470
AP_RUQ7TN544094JKU0FHGUXY
CAPACITOR, 22pF, 0603, COG, 50V, 5%; OEM P/N: 188454-220
AP_XI3J5N444TBUUL7FKT0IXM
INDUCTOR, 100uH, SMD, 20%; OEM P/N: 256773-101
AP_E8E59LQ6Q4FJSDMW3FBX0Z
BEAD, FERRITE, CHIP, 1806; OEM P/N: 256116-181
AP_7YIH7NX1GC59L1COSUKVHZ
FERRITE, 400 OHM, CHIP, 0805; OEM P/N: 188587-401
AP_R5BE9AASC5F19HEKKD8MOD
INDUCTOR, 2.2uH, COM MODE; OEM P/N: 187598-2R2
AP_OUMXRJ78NTRDQKKFD7TO05
POTENTIOMETER, 10K, 20%; OEM P/N: 273741-001
AP_F59EBA8VB427VFX9C6AR7P
RESISTOR, 0.075 OHM, 1210, 500mW, 5%; OEM P/N: 318356-750J
AP_ZWRZMS02GSULEORNCZCCJ4
RESISTOR, 0.10 OHM, 0805, 1/8W, 5%; OEM P/N: 304926-R10
AP_K4ORZ9DB8HF2D5HXEGXTIU
RESISTOR, 22 OHM, 2512, 1W, 5%; OEM P/N: 181895-22R0
AP_S73YT8P9XH2B5QUFYY17PP
RESISTOR, 200K, 0603, SMD, 1W, 5%; OEM P/N: 199403-204
AP_MH0H708ADGAA8ISQPRXSOX
RESISTOR, 1M, 1206, 1/4W, 5%; OEM P/N: 124895-1055
AP_HXUYRPF5QS6XIU7YGP99G7
RESISTOR, 150K, 1206, 1/4W, 1%; OEM P/N: 124894-1503
AP_FI7IDD8IEJMC833KS4QM2O
RESISTOR, 47OHM, 1206, 1/4W, 5%; OEM P/N: 124895-4705
AP_Y6A043SQW43QJTDK5HIOC7
RESISTOR, 3.9K, ARRAY, SMT, 4 POS, 5%; OEM P/N: 186433-3924
AP_M9P0HG7WEM4LGPSSB2E05Q
RESISTOR, 1.8K, ARRAY, SMT, 4 POS, 5%; OEM P/N: 186433-1824
AP_M9JSA5R8F9GD7MK2QEPEJI
RESISTOR, 510, ARRAY, SMT, 4 POS, 5%; OEM P/N: 186433-5114
AP_RX1Q9OK5Y49D21X1GMT8GE
RESISTOR, 470K, 0805, 1/10W, 5%; OEM P/N: 133626-4745
AP_MNG0P5FCHX4C8QMAXOVL0V
RESISTOR, 1.00K, 0805, 1/10W, 5%; OEM P/N: 133626-1025
AP_Y1ASRM787JNO1G08NK4GBU
RESISTOR, 200 OHM, 0805, .125W, 1%; OEM P/N: 133625-2000
AP_03O6LS1B86W3ROH2I4BW6G
RESISTOR, 102K, 0603, .1W, 1%; OEM P/N: 191465-1023
AP_XBL24RH6ZMIZXX175L7BQ9
RESISTOR, 100K, 0603, .1W, 1%; OEM P/N: 191465-1003
AP_WCYH798G2QXJNQ79YUPMJ8
RESISTOR, 100K, 0603, .1W, 5%; OEM P/N: 199403-104
AP_0MQ3OSJ1GWX1AMYOPPDJ9X
RESISTOR, 68.1K, 0603, .1W, 1%; OEM P/N: 191465-6812
AP_V7HO5IHSG29E89DHXYA98U
RESISTOR, 64.9K, 0603, .1W, 1%; OEM P/N: 191465-6492
AP_8CUN75EJICH2RBG3Z0H7GJ
RESISTOR, 60.4K, 0603, .1W, 1%; OEM P/N: 191465-6042
AP_DF92RA7PIODRXR8CPRW8GR
RESISTOR, 47K, 0603, .1W, 1%; OEM P/N: 191465-4702
AP_H48FZZDB313JCC3NADPFLM
RESISTOR, 47K, 0603, .1W, 5%; OEM P/N: 199403-473
AP_KNOSNGL24XIQ1TWKC8PHER
RESISTOR, 40.2K, 0603, .1W, 1%; OEM P/N: 191465-4022
AP_HV4MD0JQ8N4OJFCK9RNVU5
RESISTOR, 30.1K, 0603, .1W, 1%; OEM P/N: 191465-3012
AP_TSEQ01FOS2WSEJZELSAN6A
RESISTOR, 26.7K, 0603, .1W, 1%; OEM P/N: 191465-2672
AP_CPB6HFICW5LWIAPJ7CFA8X
RESISTOR, 10K, 0603, .1W, 1%; OEM P/N: 191465-1002
AP_LHGUUL6TGD4KSOPY42BPJW
RESISTOR, 10K, 0603, .1W, 5%; OEM P/N: 199403-103
AP_8ZUW7GHFTWS6SDDUJCXWQU
RESISTOR, 8.66K, 0603, .1W, 1%; OEM P/N: 191465-8661
AP_JQ0HMVVKF3XUL7W3ON9NVD
RESISTOR, 7.87K, 0603, .1W, 1%; OEM P/N: 191465-7871
AP_FCX37MBMHSTMT3T2QZNGA1
RESISTOR, 4.7K, 0603, .1W, 5%; OEM P/N: 199403-472
AP_28HIBKISPQ8TYH6B1FZPBN
RESISTOR, 3.32K, 0603, .1W, 1%; OEM P/N: 191465-3321
AP_NV9QQPM4E4VKAHSJ4EMD5A
RESISTOR, 3.3K, 0603, .1W, 5%; OEM P/N: 199403-332
AP_ENKE9OBLPK0HP26BM9B5CU
RESISTOR, 2.49K, 0603, .1W, 1%; OEM P/N: 191465-2491
AP_IUG0MA0MTP92ZRR7GT40TW
RESISTOR, 2K, 0603, .1W, 1%; OEM P/N: 191465-2001
AP_ONECL4KBEPEPKQZX0E3AC5
RESISTOR, 2K, 0603, .1W, 5%; OEM P/N: 199403-202
AP_9LUASJ4L2TEQJZH98ROZ4W
RESISTOR, 1.21K, 0603, .1W, 1%; OEM P/N: 191465-1211
AP_WMN4EQ9P87JC1G2I21F5BL
RESISTOR, 1K, 0603, .1W, 1%; OEM P/N: 191465-1001
AP_UAUDHWFDMI4UZK62MWWRAO
RESISTOR, 1K, 0603, .1W, 5%; OEM P/N: 199403-102
AP_XBJUNE51CBZLO7FXSRHHNW
RESISTOR, 470 OHM, 0603, .1W, 5%; OEM P/N: 199403-471
AP_F928781ZQH7WF3HFKJLBSM
RESISTOR, 402 OHM, 0603, .1W, 1%; OEM P/N: 191465-4020
AP_IPNIZ6E1BJ60XCBFNI1772
RESISTOR, 100 OHM, 0603, .1W, 5%; OEM P/N: 199403-101
AP_IFALGFNNK2M9176V380GN9
RESISTOR, 75 OHM, 0603, .1W, 5%; OEM P/N: 199403-750
AP_ZHUPYVPG6P0S5SW7JK36CE
RESISTOR, 47 OHM, 0603, SMD, 100MW, .1W, 1%; OEM P/N: 199403-470
AP_FN0P09TYCWRZDPVIQSETKK
RESISTOR, 22 OHM, 0603, .1W, 5%; OEM P/N: 199403-220
AP_XG80EXF62J14BVT86BTEST
RESISTOR, 10 OHM, 0603, .1W, 5%; OEM P/N: 199403-100
AP_06JHV7S4358HHF1RTEWOF3
RESISTOR, 3.32 OHM, 0603, SMD, 100MW, 1%; OEM P/N: 191465-3R32
AP_801TOYBWLLG415IKWYI9F0
RESISTOR, JUMPER, CHIP, 0603; OEM P/N: 196042
AP_IHHYS1LJ7HM0MFE5266CP7
CONNECTOR, AC, SINGLE PIECE LEADS; OEM P/N: 301125-001
AP_IBZ7B5S0EB3NGUCTSBDMK2
CONN, D-SUB, R/A, FEMALE, 9 PIN; OEM P/N: 285818-001
AP_PCWBZJ3I6HRIVMHD26658Y
CONN, D-SUB, R/A, 9 PIN, SOCKET; OEM P/N: 285805-09
AP_UY4XW4PPITCCAYYLQYCECF
CONN, DUAL ROW, 16-P, 0.1mm, SHRT LATCH; OEM P/N: 323689-016S
AP_49U90G2IYATG6U3E4YEB13
CONN, HEADER, LOCKING, TOP, KEYED; OEM P/N: 271897-002
AP_OH9CXUO80YIQR2A22HC7BD
CONN, HEADER, PC MNT, KEYED; OEM P/N: 271899-010
AP_W4RUX2YF9WS4FLVHQ8AJKX
CONN, HEADER, 2.5MM, THRU, 16 POS; OEM P/N: 270584-016
AP_AK34I2H5PO4RKQHWIDYD00
CONN, HEADER, RTANG, 2.5MM, 10 POS; OEM P/N: 145402-10
AP_BZFZCXWPSHW0D9UOWU0FIB
CONN, THRU BOARD, TH, 4 POS; OEM P/N: 266952-04
AP_XOYYHIM86VQWHSDAV384P1
CONNECTOR, HEADER, RTANGLE; OEM P/N: 190552-03
AP_KLDSJQQENGWXG0QP751PPI
CONN, SIDE ENTRY, W/PCB STAB; OEM P/N: 258436
AP_NI4OMZ57B0AQLCXIDJKWFR
PAD, THERMAL, COMPLIANT; OEM P/N: 266954-001
AP_69GTGPWENCTT2WW1K3LYIW
PAD, THERMAL; OEM P/N: 323653-0010
AP_QPFC636ASP774QTPT09VXA
GASKET, EMI, HEATSINK, 33MM; OEM P/N: 276873-002
AP_272YTUNUV7IC42E4NDNE7F
GASKET, FOAM, .32"X12.0"X.125"; OEM P/N: 255202
AP_E8SXFE2NHTIVIQ9OY1HPPJ
PAD, FOAM, .25" X.75" X.06"; OEM P/N: 278144-001
AP_WHS48UU1XPJDQ54N8TYJP0
NAMEPLATE, BOSE LOGO; OEM P/N: 319457-0010
AP_8J2H487I1HGKWM55VRD581
NAMEPLATE, BOSE LOGO, PREVIOUS REVISION; OEM P/N: 269981-001
AP_296MQCGYP85BC0RE1LN9RU
BUMPER, RECESSED, FOOT, .88"; OEM P/N: 142839
AP_8CCZ8GZP4SHFZRKKRGT2ML
FOOT, CLEAR, .312x.085, 4'; OEM P/N: 178321-04
AP_K095C8WXLO5XL0GSROGNB6
REMOTE BATTERY, CR2032/DL2032, 3V LITHIUM
AP_W7TSI0SQIBDFNGWTRPPNNY
SPEAKER ARRAY INTERNAL WIRING HARNESS
AP_WVV0TQB72UV2D2QRNDJ40C
SPEAKER ARRAY ENCLOSURE, BASIC
AP_4QIFEYOSLKKS9WBDV4S3AS
SPEAKER ARRAY ENCLOSURE, GEMSTONE
AP_HQ39QPAP3HGG91R4MOQ2E3
SPEAKER ARRAY ACOUSTIC DAMPING MATERIAL
AP_RRIJ82U5GZO013L9FQSMYI
BASS MODULE INTERNAL ACOUSTIC DAMPING MATERIAL
AP_2VGFMU2KBNISCN9AMPEBPO
BASS MODULE DRIVER GASKET
AP_W6BVJU03YSWKLMKJA39GIB
BASS MODULE REAR ENCLOSURE GASKET
AP_6YXRDAKXUYJ2DUBLAC2GDO
INTERFACE MODULE CABLE STRAIN RELIEF
AP_P8HR44H6ZVPAIB39EZZ5IY
SCREW, TT, 8-32X0.5,PAN, XREC/SQ; OEM P/N: 289393-008
AP_J3EXKH79TGM50IX31LVR6M
SCREW, TAPP, 6-32, PAN, TORX; OEM P/N: 279948-08
AP_PRM6S53DLAAJAR3D8W4QZA
SCREW, TAPP, 8-11x.75, PAN, XRC/SQ; OEM P/N: 289388-012
AP_AHU8R1SDID3A9AG8JL3FUA
SCREW, TAPP, 8-11x.437, PAN, XRC/S; OEM P/N: 289388-007
AP_V4NM0OZKZQOUKJN4L4A129
SCREW, 6-13x.5, PAN, XREC/SQ; OEM P/N: 288374-008
AP_Q15Y5JF4J97DCJJVY5WYCY
SCREW, HILO, 4-16 x .375, PAN, XREC; OEM P/N: 288372-006
AP_GXTBG2ZNJ3D5P24PM9HBRH
SHIM, DSP PCB, SNAP HEATSINK; OEM P/N: 319839-0010
AP_7V4CE0A4873Y54ZPXY8NVS
DSP FIRMWARE IMAGE, CINEMATE SERIES II
AP_BNFGRP90VU65LDPI8XYS0X
DSP FLASH PROGRAMMING SERVICE IMAGE
AP_9DDZO77O81W6NC5L1KU97R
DVD SET-UP DISC, CINEMATE, NTSC; OEM P/N: 318861
AP_OJGEWG28P1C7H83LJ95HPD
QUICK START GUIDE, CINEMATE SERIES II GS; OEM P/N: 323022-0010
AP_UOW5WZGRB3JCFG5U04L9SI
GUIDE, OWNER, CINEMATE SERIES II, US/AIM; OEM P/N: 323023-0010
AP_GHKZMWTAHMGQF8BGINKJTV
GUIDE, OWNER, CINEMATE SERIES II, APAC; OEM P/N: 323025-0010
AP_0T1AI097F4PDC4E5WRFJUE
CARD, REGISTRATION AND WARRANTY; OEM P/N: 262933
AP_RQXIHZHOK9T05W0QFVMX5I
SHEET SLIP COMPONENT AUDIO; OEM P/N: 255805
AP_DAXLOFEAZ40N1HK2G0IQ04
SERVICE MANUAL, CINEMATE SERIES II / GS SERIES II, REV. 11; OEM P/N: 318842-SM
AP_B08CGTBAIO69TIEZ8ASLXM
SERVICE BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-B1
AP_GAOY4JJLA3B5I25RQGENME
SERVICE BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-B2
AP_R31MJCO67HNOT21JWVHMAQ
SERVICE BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-B3
AP_RMBS4ASW1XKHNMMKJVZS04
SERVICE BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-B4
AP_H3TA657R3EYDDWUKFRP5L8
SERVICE BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-B5
AP_6JL5S5ZEDSJ36CX876LFEA
SAFETY BULLETIN, CINEMATE SERIES II; OEM P/N: 318842-SB1
AP_UQ793Q9GT0O01VRY43U7PY
TROUBLESHOOTING TIPS, CINEMATE SERIES II; OEM P/N: 318842-TT
AP_WW232IY1BCME47DP7TSIYH
LITERATURE KIT, 120V
AP_MVENPOQP6WITK6VLMTDJDR
BATTERY, AA, BAGGED & LABELED; OEM P/N: 194392
AP_Q7TPB18MFRIA67RYLHRSN9
PACKING, INSERT, EPS, BASSMOD, CINEMATE GS; OEM P/N: 370944-0010
AP_XMCV94LKCXJHZ90SLT4ZQI
PACKING, INSERT, EPS, BASSMOD, CINEMATE; OEM P/N: 319347-001
AP_IGBWXXMXKQL7HG76GWAYHG
PACKING, INSERT; OEM P/N: 267071
AP_UC7QFRWGKN98PUCWZQ80W7
CARTON, RSC, 23.75X19.4X12.25, CINEMATE II GS; OEM P/N: 320576-0001
AP_3TG3NLNKVSEA7TDZTRTDDJ
CARTON, RSC, 23.75X19.38X12.25, CINEMATE II; OEM P/N: 319345-001
AP_YXL7NE0HS8N6MC1Q46FX2W
CARTON, D/C; OEM P/N: 286868
AP_GZWQYAIVAPQSD9L2UK0DLF
BAG, FOAM, 28"X24"X.03"; OEM P/N: 322279-0010
AP_5AH35L4HAH1EO7VR1HZILK
ACCESSORY KIT INNER POLYBAG
AP_UX3Z47GLDTF78BB9J0E5SU
REMOTE CONTROL PROTECTIVE BAG
AP_Y7GCABAATPXCQ28P9AMY91
POWER CORD POLYBAG
AP_UNPK7UT3KE8YX2JETY38RW
CABLE SET POLYBAG
AP_ZV2ID9NPE69PX369CLHWP0
ESD PROTECTIVE BAG, DSP PCB
AP_C4S6M28DY7CWZ8GIONJ6FY
ESD PROTECTIVE BAG, POWER SUPPLY PCB
AP_RCJB0Y8BP1CFP2JMOOSRN8
ESD PROTECTIVE BAG, I/O PCB
AP_P2CQD3WNAHJP56M0C45VZG
PACKAGING TAPE, SHIPPING CARTON
AP_VY3A8L55JSETRT3WBT1RZ0
PRODUCT SERIAL NUMBER LABEL, BASS MODULE
AP_WKB0V3C84QP0GYZ0HIF9JJ
REGULATORY/RATING LABEL, BASS MODULE
AP_EWUHJWC6FCNQQATRTCUPIQ
REGULATORY/RATING LABEL, INTERFACE MODULE
AP_AV52NPMIKPLMCUI5Y1414K
COUNTRY OF ORIGIN LABEL
AP_3P4GCAEPMNFPFTKT78W3M5
BARCODE/UPC SHIPPING LABEL
AP_TMF8EXUSKJ3XSFV8U0CIK0
WARRANTY SERVICE RETURN LABEL
Repair, service & parts, for your Bose CineMate Series II
- 1 Repairs are performed on a best-effort basis. Acme Revival utilizes a network of sophisticated technicians and engineers with diverse service offerings; despite this, factors that influence the repair outcome may ultimately prove unsuccessful. Acme Revival makes no claim that it can, guarantee a repair before your device is sent in for diagnostic evaluation; even then, repair and diagnostic work are not mutually exclusive. Despite well-intentioned quoting, repairs may still prove unsuccessful.
- 2 Parts known to Acme Revival via Acme’s Neural Network and documented discovery. These parts may not represent OEM cataloging nor does Acme Revival guarantee display accuracy. Always check with Acme’s Help Desk to ensure availability and accuracy. Parts may not be in new condition, may be unavailable, discontinued, or not offered for independent sale.
