Acme Revival connects your Bose 1600 Power Amplifier with a nationwide network of skilled electronics technicians built to fix what manufacturers won't. Start online, ship it in, and track every update and outcome in one transparent Service Dashboard.
1
Repair
$107.00
FLAT-RATE REPAIR (LABOR)
90-Day Warranty
No-Fix Repair Guarantee
Revival’s flat-rate repair service is a best-effort attempt to diagnose and repair the reported issue. The advertised price covers technician labor only and will not increase.
If replacement parts are required, we’ll provide a separate quote for your approval before proceeding. If we can’t complete the repair, your labor charge will be refunded. A separate $25 Repair Network Service Fee applies, along with return shipping & handling. These charges are non-refundable.
Repairs may be limited by device condition, prior damage or modification, safety concerns, or unavailable manufacturer-controlled parts or resources.
Most Recent Repair Requests:
2 (Known) Parts List:
AP_7IAVRSFECQKE9BUMUFS3QH
PCB Assy, Amplifier, 1600VI; OEM P/N: 199781
AP_C5P8ZJZ9U5DYSG6LT74OIQ
PCB Assembly, Power Supply, 1600VI; OEM P/N: 199782
AP_H7QMGPI2TCVOXK1T6F56LD
Bose ACM-1 Amplifier Control Module
AP_152G5UT2JJU3NNR1OAP9EO
Transformer, UI, 1600VI, 750W, IEC, 230/240V; OEM P/N: 199783
AP_HXLTGR19QNZQXP537DRUGA
Transformer, UI, 1600VI, 750W, 120V; OEM P/N: 199784
AP_NM1AW42NCMPJ6FTDK09C29
Transformer, UI, 1600VI, 750W, 100V; OEM P/N: 199785
AP_JIIN8EPKHVZ4RJDTT79CIU
PCB Assy, Input/Output, 1600VI/1800VI; OEM P/N: 182758
AP_NNM1NWC4KJ1K0COTC67XOS
PCB Assy, Input Module, 1600VI/1800VI; OEM P/N: 182755
AP_07DNCTA69Z6EXNPCVGUU16
PCB Assy, Output, 1600VI/1800VI; OEM P/N: 182759
AP_WJA8TC229PQODE7LDP1WA1
PCB Assy, Display, 1600VI/1800VI; OEM P/N: 182762
AP_O0R6LTRWUV2KDO1ABGV0PO
PCB Assy, Power Switch; OEM P/N: 182761
AP_Y6W796H9MQS5ZERHCLV7SA
PCB Assy, Barrier; OEM P/N: 182774
AP_23EIAYJOOREZ21EHRX865Q
Heatsink, Amplifier; OEM P/N: 182745
AP_3Z34P1Z2G9Y71RV8FU5NF3
Chassis, 1600VI, DOM; OEM P/N: 199791
AP_G14PFWJUGOWJDW3G7XDPBV
Chassis, 1600VI, ECE; OEM P/N: 199792
AP_CX48JN6ZOTCC38A3SKIOXN
Bose Equalizer PCB Assembly, Channel 1
AP_XD1KK9VSGP8O3JHXBK70O2
Bose Equalizer PCB Assembly, Channel 2
AP_YFSUQMC3GTFDCM29OYN6A5
Heatsink, Power Supply, 1600VI/1800VI; OEM P/N: 199794
AP_4Z7SY2QUAPS8F2GDEG6QSA
Input Module Dual Input Panel Assembly
AP_NI5DIPJI8RSKWB4ZNEV1MV
Panel, I/O, SS, Gray; OEM P/N: 199786
AP_M5KTRD6B0FMX2RSCFICMOA
Cover, PC, Gray; OEM P/N: 182740
AP_4IDW4ZBBR0LMNX36ZW1JPO
Brkt, 2U, Rack Ear, PC, Gray; OEM P/N: 199790
AP_NW3IVQCI3IZNMS6WQ2USGH
Fan, 24VDC, High Flow; OEM P/N: 182710
AP_1J3TOTEHPB5NPXGXMNPD5F
Line Filter, 16A/20A, 120V and 100V; OEM P/N: 182763
AP_3CLSYLVBVPCSZ6NMAGF3R0
Line Filter, w/Tabs, 8A, 230V; OEM P/N: 182764
AP_27UDDQQ9ZL9VNM18RA5PWG
Post, Binding, Dual, Short, Red/Black, 120V and 100V; OEM P/N: 182711
AP_42IDJ6LASNV2ML9D39Y0PE
Bind Post, Dual, Short RT Entry, 230V; OEM P/N: 182712
AP_0Z5LRVKTC6O1IBF6WZ8I5R
Bind Post, Dual, Short LT Entry, 230V; OEM P/N: 182713
AP_VOZJAJJ77PZVGJJQKIK7R4
22000uF, AE, SCR, 20%, 50V; OEM P/N: 199760
AP_PQB1GNRMNH5JOY12VEOGRB
NPN, 2SC3281, Motorola, TO3PL; OEM P/N: 182813
AP_QBVW6CUPV7QX0KBC6OABQK
PNP, 2SA1302, Motorola, TO3PL; OEM P/N: 182814
AP_US7I48LHHC7ZP39KWMENGC
Rectifier, Bridge, 25A, 400V; OEM P/N: 182866
AP_3A5SWM1499XOFKLM3VM5A4
Triac, Q6025k6, 25A, 600V, TO218AC; OEM P/N: 199765
AP_RJYN6187YGTH2GN5B7AWB9
Relay, SPST, NO, 24V, 20A; OEM P/N: 182942
AP_IFBHWZ6MNX5RE6KSC04HV9
Pot, Rotary, 11 Det, Wire Tabs, 1KB; OEM P/N: 182735
AP_Q7NHR57O3MDBWHVH91M5H1
Jack, XLR/TRS, Right Angle; OEM P/N: 182984
AP_T2C0KYTD1S83XNSSR7SY5P
Bal Line Rcvr, SSM2141; OEM P/N: 183005
AP_UIR9VHKJP9HLLV710CO1XE
Op-Amp, w/Switch; OEM P/N: 183004
AP_GXP3TAJTJ11DNUEHC3QYEP
Optoisolator, VTL5C4; OEM P/N: 199766
AP_N8LQ1MMQLH6NNWKMUGGVC1
Rectifier, HW, Com Cathode, 16A, 200V; OEM P/N: 182865
AP_AQ3MRNMGWYPPAM52GWGRPQ
Rectifier, HW, Com Cathode, 16A, 200V; OEM P/N: 182864
AP_7IV3J0FHZ19BOFY3OO976J
N-Channel MosFET, IRFZ44, TO220; OEM P/N: 182878
AP_TWLH2FGHL95NR65USV23QJ
NPN, 2N6488, TO220; OEM P/N: 182876
AP_9EJU0WL91FM73L69OV2RYR
PNP, 2N6490, TO220; OEM P/N: 182877
AP_PHPRIBLW37RICRU9727A37
Choke, 5uH, 14AWG Wire; OEM P/N: 182941
AP_EO783A5CLTDSKZAYELRMBH
Dual Volt Comparators, LM393; OEM P/N: 182879
AP_ZWDZSDM2ZOMYWTFKB1L2CB
Dual Op-Amp, Bi-FET, TL072; OEM P/N: 182821
AP_S76MQV1JWKYSYWR3IYCVZK
Op-Amp, Dual J-FET, 9 pin, SIP; OEM P/N: 182915
AP_P5U8OV1B3ZNL3TR71CYBNG
Dual Op-Amp, 4558, 8 pin, SIP; OEM P/N: 182914
AP_NRZYYG1IPZCSMDUIT82ZX7
Bridge Rect, 50V, 1.0A, DF005; OEM P/N: 182912
AP_U7H44TY0BIUIGXQNGXBKML
NPN, 2SC3503E, TO126; OEM P/N: 182819
AP_HFN7M9GVC45L57509B2AOY
PNP, 2SA1381E, TO126; OEM P/N: 182820
AP_GTADEG1H0YAZW58IBXP4YH
Rocker, SPDT, 15A; OEM P/N: 182969
AP_2OHGVXQ6RZ5S1WSQE2TM5D
Switch, Rocker, SPST, QICDIS, 15A; OEM P/N: 183550
AP_6E9O88TUVMEBKN98O1Z4XT
Fuseholder, Panel Mount 120/230V; OEM P/N: 182706
AP_S1TFI6IEFST01RMO3KPMRD
Harness, Conn, 13p, 22AWG, 23in; OEM P/N: 182754
AP_13OB4N8RZU7GE3SZVAOCDE
Harness Connector, 16p, 18AWG, 6in; OEM P/N: 182824
AP_0OSANMNSBTSCNQV32VYH3Z
Harness Connector, 10p, 22AWG, 4in; OEM P/N: 182823
AP_D27OG1FASTB1D53Y1W81XM
CAF, 2x10, TRANS, 2x10, RCPT, 6in; OEM P/N: 182919
AP_2JQKTRCQ7S9VG2LS9F316Q
CAF, 2x7, TRANS, 2x7, RCPT, 6in; OEM P/N: 182918
AP_ITMVN07GXQ3GI7HC1A7QRO
Cable, Shielded, 3 cond, 22AWG; OEM P/N: 199767
AP_9H431HR77LAD6LIE1OYFWS
Harness, 2p, 22AWG, Blind Mate; OEM P/N: 182920
AP_RC8L7UR9FRCD5SIBKWJF6K
Phone Jack, 1/4, PCMT; OEM P/N: 182985
AP_MLMVJDJEYQ3CP3KVBEPUYT
Slide, DPTT, Rt Angle; OEM P/N: 183002
AP_F4AOUA1LVVJI73A8RD8J19
Slide, DPDT; OEM P/N: 183001
AP_FYF9QSXDNJDDG9Q8SY56A9
Line Cord, Euro, 16A, 7ft.; OEM P/N: 182737
AP_2JM9E57G72FZS2T58MRG3K
Line Cord, 14/3, SJT, SHLD, 15A; OEM P/N: 182738
AP_0TDGV3JW04YLLCMGKDM1XN
Line Cord, Australia; OEM P/N: 199769
AP_V43KXLIX5WTNWOFN17E4QM
Line Cord, 16/3, SJT, SHLD, 13A; OEM P/N: 199768
AP_H7FJO2LXYAGEJRYTC4SI86
Brkt, Heatsink; OEM P/N: 199787
AP_QOJXGUSE0QW0GH98KX716Y
Brkt, Connector; OEM P/N: 199788
AP_MWU4BYSJHDY3QY9E994BQD
Bracket, Connector; OEM P/N: 182742
AP_ET7PGK9UY4HUN0MCBB4CS2
Shield, Fan, Lower, Fab; OEM P/N: 182751
AP_JOHANJDMHNW6O10JQE0H2I
Shield, Fan, Upper, Fab; OEM P/N: 182748
AP_1YUFLGQU97JXDDHUOI6Y9A
Shield, Noise, Q214, 216; OEM P/N: 182749
AP_D8QJUK3DM3FMOTVFUIU7M3
Shield, Pot Noise, over leads R102; OEM P/N: 182750
AP_4UGSB2E1C9U6BSCQ3707CM
Brkt, Shield, Fab, PM1400/1800V; OEM P/N: 199790
AP_W9VCJO7C864J57XDEUHWPN
Knob, Soft Touch, 13mm; OEM P/N: 182744
AP_NZBBI5HWINHO7HOX9L2Z7Z
Fuse Carrier, 100V; OEM P/N: 182707
AP_91CAKOPKCQD80FO9TUVHRF
Fuse Carrier, 230V; OEM P/N: 182708
AP_PZF6AHD1I1P06MGFCBSRBE
Insulator, Sil-Pad, K-6, 7-Pos; OEM P/N: 182747
AP_3SIXMC9OVCK106EQOLV44P
Insulator, Sil-Pad, K-6, 8-Pos; OEM P/N: 182886
AP_OVDTI2C7DSKMK8Y3YGQL5Y
Insulator, Sil-Pad, K-6, TO216; OEM P/N: 182887
AP_EBGLJX4B6X1UBQ5OSVI908
Insulation Film, .010 thick 2.2” x 14” Heatsink, 7” x 10.5”; OEM P/N: 182709
AP_15X9ON7NATOXD09XE0B5KH
Opto-Triac Driver, MOC3052; OEM P/N: 182880
AP_53EEJYEOKQQV0KYMNPUWO3
PNP, MPSA93, TO-92; OEM P/N: 182873
AP_OCN8VZRG3TJCE0ZQW5WVBD
NPN, MPSA06, TO-92; OEM P/N: 182874
AP_YT2MZDHC54FD2Y0AA8K4NL
PNP, MPSA56, TO-92; OEM P/N: 182875
AP_YVO4FUURKSN3FZT1HQI413
NPN, MPSA43, TO92; OEM P/N: 182872
AP_ZW3X9HD933PBPV5U8HRZI5
NPN, MPSW06, 152, SM SIG; OEM P/N: 182871
AP_M2RW9IQFBCGUPFWA6W07LQ
NPN, MPSA42, Small Signal; OEM P/N: 182817
AP_D0GMU3LDNXIKLDT6R6FGK4
PNP, MPSA92, TO92; OEM P/N: 182818
AP_4M90TVFE0S70DEEV6N6CLU
NPN, MPSA18, TO92; OEM P/N: 182816
AP_65NDKC07VGPK7YOETHSXLF
PNP, 2N4125, TO92, Small Signal; OEM P/N: 182815
AP_J2KP6B7JY6ITQIUKV60FRP
NPN, 2N4123, TO92, SM SIG; OEM P/N: 182913
AP_E3JEP80AN78TNVKPFOLYLX
PNP, MPS6729, 152, SM SIG; OEM P/N: 182938
AP_B5TDFLEOMT5GB9V220QK47
1SS143; OEM P/N: 199762
AP_IAXI5XWWE8F41UFKJOBA4J
1N4004, 400V; OEM P/N: 182811
AP_Z1ODIU3N6HWVBAKXGXX1VL
1N4148; OEM P/N: 182868
AP_MA8UMCX08HSHCRFIQ4692S
Zener, 1N4745C, 16V, 1W, 2%; OEM P/N: 182870
AP_K2W0975NL1069ZZ9TY8QW2
Zener, 1N4744A, 15V, 1W; OEM P/N: 182869
AP_DN1DMNJJI6UA1BXRJCF6WG
Zener, 1N4746A, 18V, 1W; OEM P/N: 183003
AP_NQXMGM279J0NKRKYQG5HZ3
LED, Red/Green, 3mm; OEM P/N: 182982
AP_SELS19TAVWRXMZU372MI21
LED, Yellow; OEM P/N: 182981
AP_I9M1NCA95JAC0LBHS0193A
LED, Yellow; OEM P/N: 182970
AP_7HDIY8F7JA53MOAPTWNFMT
LED, Red; OEM P/N: 182980
AP_2WX5DB8RW6AV2N63PGCL3V
LED, Bi-Level, Grn/Grn; OEM P/N: 183020
AP_GWJA1FADHI5DQZ1ON5UCGP
Header, 20 pin, Rt Angle, Vert Ejector; OEM P/N: 199759
AP_PNSS80TTSAZJ51KI27TYSX
Header, 13p, .1 CTR, Rt Angle, Flat; OEM P/N: 182889
AP_0SF4IGBSL5HH3K2PIJVXPN
Header, 10p, Right Angle, Square; OEM P/N: 182888
AP_UW0HJ7R9BVXPV7BGP35G0T
Header, 14p, Dual Row, .1 CTR, G; OEM P/N: 182922
AP_PNKIV20SKMC1AVN1AGMSXY
Header, 2p, .1 CTR, LOCK ST POST; OEM P/N: 182921
AP_D1GHR5YHT1RHYOU050QIN3
Header, 13p, .1 CTR, Lock, Rt Angle; OEM P/N: 182972
AP_EZWQM9ZW382B55C3GSVJV5
Header, 20 pin, Dual Row, .1 CTR; OEM P/N: 182988
AP_S81WS67I9OU0Y22APWN5O2
Header, 4 pin, Rt Angle, Blind Mate; OEM P/N: 182991
AP_VH3SWNLRDI2EUUQH3DFGNZ
Header, 90deg, Closed End, 3 pin; OEM P/N: 182990
AP_DMIJSHX1YJH84KY54YR69M
Header, 12 pin, .098 CTR, Shroud; OEM P/N: 182987
AP_JYFS5Y3BY24BR3JECS1H0A
Header, 6 pin, Dual Row, .1 CTR, Gold; OEM P/N: 182989
AP_L9XWNTWCCEQAU81QYATP79
Connector, Mini Link, .10; OEM P/N: 182986
AP_3ZKNBHRTJ6JUUSLS3Z7RPE
Connector Tab, .250, PCMT; OEM P/N: 182825
AP_TRDGVS9P72F6ZXQQJNJ82I
Conn, 18 pin, Single Row, .100, Gold; OEM P/N: 182833
AP_Y6890T1PBVW4XVWJLC75RQ
Header, Square pin, .156 CTR, Tin, 16 pin; OEM P/N: 182834
AP_6LKTPZYSK5RVQ9ZE7HYF2N
Term Block, 2p, .15 CTR, Angled; OEM P/N: 182967
AP_MM0O5ZFNNXM4UXWPIADXUF
Plug, Right Angle, Term Block, 3 pin; OEM P/N: 182769
AP_ORCFPYCOWZ0S496O300IF2
Connector, .100 ctr, 2-pin, on fan wires; OEM P/N: 182733
AP_3G198041FNYIC7PHYYK5JH
Fast NYL, 16-14 AWG, Blu .250; OEM P/N: 182734
AP_B3X4XN90C9YCOPRBPYCHCA
470uF, AE, AXL, 20%, 63V; OEM P/N: 182842
AP_V4TYCWMWLZOANL47I776LF
470uF, AE, AXL, 20%, 6.3V; OEM P/N: 182783
AP_IK07BO9ZOWMORBRCVNSP0V
220uF, AE, SNP, 20%, 10V; OEM P/N: 182899
AP_TASRNIH8YDES0OF8TTD1PR
220uF, AE, Radial, 20%, 16V; OEM P/N: 182993
AP_7BD1XPH88NOQ3VT5T0GSEY
100uF, AE, AXL, 20%, 25V; OEM P/N: 182843
AP_89T77009E1PH85RKIXXTC9
47uF, AE, Radial, 20%, 25V; OEM P/N: 182896
AP_X63UEP5P524JR058K9LA6M
22uF, AE, AXL, 20%, 35V; OEM P/N: 182782
AP_814AJN17GQM0U9T2ZSXAIX
22uF, AE, Radial, 20%, 25V; OEM P/N: 182841
AP_3NH5DO4BLOVSL2AA1SNPTX
10uF, AE, Radial, 20%, 100V; OEM P/N: 182845
AP_U4DZW11MRJGQVULAYSKGOQ
10uF, AE, Radial, 20%, 50V; OEM P/N: 182895
AP_NTLS0M4MKVSIXY2W35CZN1
4.7uF, AE, Radial, 20%, 100V; OEM P/N: 182894
AP_FFW572N3Q9D4TZQGFZWBMA
4.7uF, AE, Radial, 20%, 63V; OEM P/N: 182924
AP_ZJHT2H97GHVZVFCHDQC95J
4.7uF, AE, Radial, 20%, 35V; OEM P/N: 182925
AP_AY7REZ7GDC6SJ7DVR4L3YJ
4.7uF, AE, AXL, 20%, 50V; OEM P/N: 182784
AP_VRWINYS06MWG6R6HCM4BLG
1uF, AE, Radial, 20%, 100V; OEM P/N: 182898
AP_OQK8XCUV2C2EXDP5BMNM7E
1uF, AE, AXL, 20%, 50V; OEM P/N: 182973
AP_JQKHAPEZUEX1ADSQLEN0FS
.33uF, MPE, Radial, 10%, 400V; OEM P/N: 182923
AP_UDQ2FDPSBH9EYOA6W7AXLD
.18uF, MPE, 5%, 50V; OEM P/N: 182893
AP_HMJ9A9PU9I0B4MDXWCELXU
.10uF, MP, 250VAC, UL/CSA; OEM P/N: 182846
AP_BSFL5FRVYDJWKUDH1SD0IB
.1uF, CRML, 20%, 100V, X7R, 5mm; OEM P/N: 199761
AP_PFHAMICMPQRK4155TVFITL
.082uF, MPE, 5%, 50V; OEM P/N: 182781
AP_DDNK5XVD2LKDPL8AIXYD37
.047uF, CRML, 20%, 200V, X7R; OEM P/N: 182837
AP_ECC33F6M1OFFM9MXB2JCYL
.01uF, Ceramic Disc, 20%, 500V; OEM P/N: 182836
AP_0WKNUDCTEBFW6E57NZAR3B
.01uF, CRML, Radial, +80 -20, 100V; OEM P/N: 182780
AP_7OI0WIE1Y8VUAXZEEAS5CW
.0018uF, PE, Radial, 10%, 100V; OEM P/N: 182840
AP_3VUYHDF6DVUXTOJOCVUAAH
.001uF, PE, Radial, 10%, 100V; OEM P/N: 182839
AP_78UEA72VY2U30ATLBT0Y62
3300pF, Ceramic Disc, 10%, 100V; OEM P/N: 183883
AP_7AHLT4TPOYWGKY82JWOA8Q
680pF, CRML, 5%, 100V; OEM P/N: 182892
AP_87IDJWB4BQ4LULA50DKYPD
470pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182890
AP_J2AUXX767T55U7H7WFT51P
390pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182835
AP_XWRBCX6RSL1P6S2SDO6AEJ
330pF, Ceramic Disc, 5%, 100V; OEM P/N: 182992
AP_FVZRHUX8CGG5BI655RF1W7
270pF, CRML, 5%, 100V; OEM P/N: 182891
AP_NOGV3NEOAKUXZRPD99BFAA
68pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182778
AP_84XPZ3EWZ3QO8J593S7NNI
50pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182777
AP_6SJ2WKWABZ70VYY7IGHBRZ
30pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182779
AP_XDSKQVGT9VK687MUR8M0JG
22pF, Ceramic Disc, 10%, 1000V; OEM P/N: 182776
AP_AQ1SXG1MMG2Y2HSFJIOPNO
0.22Ω, Metal Oxide Film, 2W; OEM P/N: 182805
AP_HZDZ3NVV0SREHMVPAFQ8AO
130Ω, Metal Oxide Film, 3W, 5%; OEM P/N: 182932
AP_YC1BMOC3DABUZPGU2712GZ
91Ω, WW, 7W, 5%; OEM P/N: 182936
AP_OGY8LVKVY06YF2XSCWEDWN
6.8Ω, Metal Oxide Film, 5W, 5%; OEM P/N: 182934
AP_LQ2P4SJLALOIM0EDJV3J6V
470Ω, Metal Oxide Film, 2W, 5%; OEM P/N: 182933
AP_V3LNR0FIYOLJ3J2Z51MUXJ
.02Ω, WW, 5W, 5%; OEM P/N: 182935
AP_KVK8GCUKXE9YNL8FP1IGRM
1Ω, Metal Oxide Film, 5W, 5%; OEM P/N: 182931
AP_88W3U7FHV2D41AZJNSTSGA
10Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182937
AP_2CSIVODGBZZDJ6YYI100DE
100k, MF, Fuse, 1/4W, 5%; OEM P/N: 199752
AP_L7ZEAZWTERE0XJS6SBU8JI
29.4k, MF, 1/4W, 1%; OEM P/N: 199754
AP_Z4359YSUJX2G1EM3LDH8B1
3.32k, MF, 1/4W, 1%; OEM P/N: 199755
AP_Z9ZCOEWGYJ8TDLTXXRS9K8
11.5k, MF, 1/4W, 1%; OEM P/N: 182907
AP_C0OF39ING3MTB4RTDMZCMQ
825Ω, MF, 1/4W, 1%; OEM P/N: 182910
AP_F1R6EXTHHX4440Q62NGD4M
10.0k, MF, 1/4W, 1%; OEM P/N: 182800
AP_9DCUNH8SOHK0F2LFVUFHX3
2.21k, MF, 1/4W, 1%; OEM P/N: 182908
AP_7SZJYF7EJ6TVDFD12609EV
2.74k, MF, 1/4W, 1%; OEM P/N: 182976
AP_5JXX0RJNWD6WF7E9LDO3A2
30.1k, MF, 1/4W, 1%; OEM P/N: 182977
AP_NRLPKIZIK0UO2TP8HW63G5
7.50k, MF, 1/4W, 1%; OEM P/N: 182978
AP_XKTC695D8OCT11LALMUQ5T
909Ω, MF, 1/4W, 1%; OEM P/N: 182804
AP_T2H54FIFLZAFZMBY2K06PX
1.5k, MF, 1/4W, 1%; OEM P/N: 182802
AP_TANVSMH91ZKO8ZLNSPI05Z
511Ω, MF, 1/4W, 1%; OEM P/N: 182858
AP_5VGQA3EZWOY4LONCOJQE9V
681Ω, MF, 1/4W, 1%; OEM P/N: 182859
AP_3QI04UEYUW0NPPSNZ43ADN
332k, MF, 1/4W, 1%; OEM P/N: 183000
AP_4L4GVB1JA3YZSKURTFC1FQ
1Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182861
AP_USRLYY6ZQLA71UV3FEPV2W
910Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182810
AP_BLVBSYSQ8YK936IHRTFWVU
220Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182863
AP_WKRX3VPN07MSWUS6A534H5
200Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182862
AP_GVOR85IJGWQ1RD68EPDL22
100Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182806
AP_HSV7TFGDQ7A0X494LHNF5W
43Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182807
AP_30GKFY6WFCOKSS7C30R5CG
750Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182809
AP_QCPB7NUP37SQ4UKI40N3V2
4.7Ω, MF, Fuse, 1/4W, 5%; OEM P/N: 182808
AP_E8DYZAYBE0C73E31SMZYIC
Pot, Trim, PCMT, 5kΩ; OEM P/N: 182786
AP_O23AM3LRTH2U6M3GOCM3Q1
1M, CF, 1/4W, 5%; OEM P/N: 182900
AP_0AEEW231URKCK1B6T2GKWF
510k, CF, 1/4W, 5%; OEM P/N: 182798
AP_A37501X5MXR8PVKOH8REXF
330k, CF, 1/4W, 5%; OEM P/N: 182904
AP_Q199QYR46OOYQIJ79TRCAW
200k, CF, 1/4W, 5%; OEM P/N: 182901
AP_NXEVM31ZJ701ASDZSY96K1
150k, CF, 1/4W, 5%; OEM P/N: 182974
AP_1XSWLGSFSW4TRO5AHBIDNX
120k, CF, 1/4W, 5%; OEM P/N: 182996
AP_DCYJ0KWEOZM108SFT2Z2VX
100k, CF, 1/4W, 5%; OEM P/N: 182790
AP_83X0ZO285KJV8SKAP02Q3V
62k, CF, 1/4W, 5%; OEM P/N: 182906
AP_IT8IJMVQ183DD1DETJ73J0
56k, CF, 1/4W, 5%; OEM P/N: 182929
AP_32O5I430SWI59L9RD95K4F
51k, CF, 1/4W, 5%; OEM P/N: 182797
AP_FSIGZ08LTAQRO4RII8ST80
47k, CF, 1/4W, 5%; OEM P/N: 182928
AP_4ANPPXM83T2RJ8TSE3WX47
30k, CF, 1/4W, 5%; OEM P/N: 182852
AP_6WQ1TU0KOUE9OO2QBFJZZZ
27k, CF, 1/4W, 5%; OEM P/N: 182903
AP_X6080OSIULJR7R45I8DVBD
20k, CF, 1/4W, 5%; OEM P/N: 182927
AP_A1V10WCA8UMMO1KOKMFQMS
16k, CF, 1/4W, 5%; OEM P/N: 182791
AP_A09I9B2G39PF6U2FGIHHA9
15k, CF, 1/4W, 5%; OEM P/N: 182848
AP_C06SL1JMUAF6C7PTQKDWN4
10k, CF, 1/4W, 5%; OEM P/N: 182789
AP_CA6J58IU4VLIXQDG2H5F0O
6.2k, CF, 1/2W, 5%; OEM P/N: 182856
AP_3539IWQW3XYDZTO7PBSSAC
6.2k, CF, 1/4W, 5%; OEM P/N: 182930
AP_IGOUF1JN1WC1QME6FUINN4
5.1k, CF, 1/4W, 5%; OEM P/N: 182855
AP_TNTGB0V7YV13ZNXEJ738D3
4.7k, CF, 1/2W, 5%; OEM P/N: 182854
AP_JX6BUBO3PXQXORLNXDBP1H
4.7k, CF, 1/4W, 5%; OEM P/N: 182796
AP_PJ0B3A0CF9QU0SSHBIMK9E
4.3k, CF, 1/2W, 5%; OEM P/N: 182795
AP_XESINZL29EEQB3YL9V31JD
3.9k, CF, 1/4W, 5%; OEM P/N: 182905
AP_0R35D5GQUYYGJDB7RA4ZER
3.6k, CF, 1/4W, 5%; OEM P/N: 182794
AP_PPU0YYQRBNKQHR91FIEB6V
3.3k, CF, 1/4W, 5%; OEM P/N: 182979
AP_HFSVQWI4JT4DP6C6DXB1G0
3.0k, CF, 1/4W, 5%; OEM P/N: 182851
AP_9BRZ4F5R7UI5AI5DT182BI
2.7k, CF, 1/4W, 5%; OEM P/N: 182902
AP_UYIRZ22ZA5LHUILG87FA3O
2.2k, CF, 1/4W, 5%; OEM P/N: 182793
AP_ON33SVHKUX0PNSIUYQ6T7Q
1.1k, CF, 1/4W, 5%; OEM P/N: 182926
AP_XD548XO2EFUZMP7OSR7W4F
1k, CF, 1/4W, 5%; OEM P/N: 182788
AP_M5M36HRB6R6S6RRR7TM0I6
750Ω, CF, 1/4W, 5%; OEM P/N: 182799
AP_T5N6SBO9Z2T4CKJP6W9LOL
470Ω, CF, 1/4W, 5%; OEM P/N: 182853
AP_4UAEZRHQ5KIIXACHPRDPXM
390Ω, CF, 1/4W, 5%; OEM P/N: 182951
AP_RG8DWPIJ5FLIQTEQLMV539
330Ω, CF, 1/4W, 5%; OEM P/N: 182998
AP_O6IYF2OZXRAVB22V005GN6
300Ω, CF, 1/4W, 5%; OEM P/N: 182997
AP_KP92EK62S7EZ07E9GGHFIX
270Ω, CF, 1/4W, 5%; OEM P/N: 182850
AP_452O8XNIXVOZKX9CRHHDMP
220Ω, CF, 1/4W, 5%; OEM P/N: 182792
AP_GXMAQWXUDLUBEMZZVE6G9V
150Ω, CF, 1/4W, 5%; OEM P/N: 199753
AP_56H34E5GJGOTYYMVXZNZTI
120Ω, CF, 1/4W, 5%; OEM P/N: 182995
AP_7DHB3C95RUDC4AK8INN87P
100Ω, CF, 1/4W, 5%; OEM P/N: 182994
AP_3618VEQUZ9Y47POUCZPJ1J
51Ω, CF, 1/4W, 5%; OEM P/N: 182999
AP_K9H1ZWNYDFC6MSNKWNIUEP
18Ω, HM, CC, 1/2W, 5%; OEM P/N: 187934-18R0
AP_9DLGYKXW4246AHPTTDBU1L
10Ω, CF, 1/4W, 5%; OEM P/N: 182787
AP_3SBYAPQQWXJ8IVNRWHNP8D
8.2Ω, CF, 1/2W, 5%; OEM P/N: 182857
AP_06PSHEF4GGL4VMXJV080T7
Thermistor, NTC, 1/2W, 5%, 1000Ω; OEM P/N: 182785
AP_9TQS2SGJ8UBHTRLA5NN1NJ
Panel, Rear, TRS; OEM P/N: 182773
AP_Y86UV4J6M1Q6MRR5KPB2OZ
Strain Relief, Threaded Nylon; OEM P/N: 199780
AP_Y53TJK1Q1DR0K9M7Z7WTPT
Slide Card; OEM P/N: 182731
AP_IWVZG19M35M63MC96YLUEJ
Clamp, Cable, 1.38, Nylon, caps; OEM P/N: 182732
AP_S8966CFT6TENOFALGWOWQE
Plug, Terminal, Blanking, Red, 230V; OEM P/N: 182714
AP_O20AX3LZBONLUY3MFYW4JS
Plug, Terminal, Blanking, Black, 230V; OEM P/N: 182715
AP_2J1HCU38Y58RET1RAH2E3C
Nut, 7mm, Metric, Dress; OEM P/N: 182746
AP_NDL1ULGN8RS3EJPOWTMHB1
Standoff, .280d x .625l, Locking Nylon, between pwr supply and reg.; OEM P/N: 199751
AP_RYOC2SY0REEOW3PULDVPT6
Standoff, PEM, 6-32 x 1/2, ST UP; OEM P/N: 199776
AP_47HPB6JY6Z0MV5O4FKHL6U
Standoff, PEM, 6-32 x .188, ST UP; OEM P/N: 199777
AP_TODMJ4LTWWEV7BOSCP6LGW
Standoff, .25od, 6-32 x .625, SWG, BRS; OEM P/N: 199750
AP_8C7VDRE0XV13SMYMICKY9C
Standoff, .25od, 6-32 x .187, SWG, BRS; OEM P/N: 199749
AP_PWDZP690HO7VYXVNBCQZC3
Spacer, Push-in .250L; OEM P/N: 182826
AP_3QOLZHC1PKSVWIRY1I752I
Stand-off, .140id x .25 SWG x .25, L, AL; OEM P/N: 182827
AP_X31MIMUNN67ZWMASEL0RH2
Stand-off, .250D, 6-32 x .125, SWG, BRS; OEM P/N: 182828
AP_0KV05K7MKUUMRHGIZQIJBR
Washer, Shldr, #4, .252 x .093, Nylon; OEM P/N: 182832
AP_CGIDXCXIA3EG22G9K6IBHX
Washer, Int Lock, #10, STZ, binding post; OEM P/N: 182730
AP_2JYSUSD6640C7G7P0YELAK
Washer, Int Lock, #6, STZ; OEM P/N: 182831
AP_P5VSXSCKO2R46U115D0YK8
Washer, Int lock, Blk #4; OEM P/N: 182772
AP_NSE2MOWT5FEAE2H8WLT2X7
Nut, 6-32 Hex, Kep, STZ; OEM P/N: 199774
AP_82CKSV3J5P4C93KR5I8P7P
Kepnut, 4-40, ZC; OEM P/N: 182727
AP_RLZ3R34KQQ65MSQGRG1AUH
Nut, 4-40, mini card slide; OEM P/N: 182729
AP_UQH0USJ40QCRLVQ1ZBJBQK
Screw, Sheetmetal, PHP, SERR, 6 x 1/4, blk; OEM P/N: 182721
AP_HZ6IDXI3LHGIMXC4L5TDT1
Screw, SEMS, PHP, 6-32 x 1/4, BO WAX; OEM P/N: 182723
AP_VLMZ0UCLO46YS8GVIEW5G8
Screw, SEMS, PHP, 6-32 x 3/8, BO, WAX; OEM P/N: 182724
AP_FC3C221GN5MBT4J6ZSA3TV
Screw, MA, FHP, 6-32 x 1-1/4, blk; OEM P/N: 182718
AP_1NFM9OROFVUW95EJZCET1K
Screw, STP, PHP, 4 x 1/2, AB, w/washer, BO; OEM P/N: 182722
AP_28NRH24ZU7BKRGLIRWIJUU
Screw, #4 x 1/2”, PHP, Type B STZ; OEM P/N: 182720
AP_FSP1RR1IRXVSGD320UN5WO
Screw, Machine, FHP, 4-40 x 1/2; OEM P/N: 182717
AP_XK62ZG41K2F83H1U7GLHLP
Screw, TF, 4-40 x 1/4, FHP, UC, ST, BZ; OEM P/N: 199771
AP_RBR35WI7DGCWN7P7JEC2ZK
Screw, PHSL, 4-40 x 3/8, Nylon, 6/6; OEM P/N: 182726
AP_JE0G3WSEZ4D49K8BHB3QSC
Screw, MA, BSC, 6-32 x 1/2, blk, chassis gnd; OEM P/N: 199757
AP_MVJ4UZMJX745W0QKRA0YGE
Screw, Sheetmetal, PHP, SERR, 6 x 3/8, B, BO; OEM P/N: 199758
AP_E22EZKRLRBIFF4H37LL4HC
Screw, MA, 6-32 x 3/16, WHSR, STZ; OEM P/N: 199772
AP_Q5MEOIWAEFDILPVUI58UZF
Screw, MA, 6-32 x 1/4, PHP, WSHR, STZ; OEM P/N: 199773
AP_1KVKMRYM61GNVXI1B181NY
Screw, TF, 4-40 x 3.8, PHP, STZ; OEM P/N: 199770
AP_SODHMWTMM7SH9R98HREECH
Screw, Machine, PHP, 6-32 x 5/8, Blk; OEM P/N: 199756
AP_CZLLMDX426HKDJRPHVVG9D
Screw, Machine, Phillips, 3x8mm, blk; OEM P/N: 182770
AP_0SHVON4UJ62SE78EZZZ8D7
Screw, SEMS, PP, BLKOX, WX 6-32 x 1/4; OEM P/N: 182771
AP_9Y41OSKFAQEG4JOLW4XL5D
Fuse, MDA, 15A, 250V; OEM P/N: 182736
AP_IWEL6Y8K2NITZKICRBRMUT
Fuse, Time Lag, 8A; OEM P/N: 183551
AP_HA45N4GIIL62TIUIX584KK
Fuse, MDA, 10A, 250V; OEM P/N: 199763
AP_WDJY3UTMVUGONPDA3R4YY2
Fuse, MDA, 7A, 250V; OEM P/N: 199764
AP_DW3Z6G99KKJPI0X4RTO7ER
Box, Shipping, 1600VI; OEM P/N: 199798
AP_2QHL6RGL7MPVYKNRUIN5E6
Foam, Packaging, 2U; OEM P/N: 182753
AP_650BLZNWLQFKVYIUHGUCQ7
Sleeve, Cord holder, 13 1/4 x 12; OEM P/N: 182752
AP_CLPCADLAL10YHC1J8V0XW5
Bag, Plastic, 20 x 30; OEM P/N: 199775
AP_GYZY1GEAGKW67RL797YOMH
Foot, Rubber, Blk, .81sq x .3h; OEM P/N: 199779
AP_EWWBRYYU0Q6YKWXKWOSDSC
Manual, Owners, 1600VI/1800VI; OEM P/N: 180118
AP_B5X3WN79O2V5WOU8806WJG
Service Manual, Model 1600VI and 1800VI Professional Stereo Power Amplifiers; OEM P/N: 199747 Rev. 00
AP_M3ER77A3GJEP9SJ7YX7K6P
ACM-1 Amplifier Control Module Service Manual; OEM P/N: 199746
AP_VK8E8N8RSGU8DSUP7P2KED
Equalizer PCB Assemblies Service Manual, 402/502A/502B/802/3202/4402/9702/LT II; OEM P/N: 181812-S2
AP_8VTS353GJTXVRDHAAXEDJ5
Equalizer PCB Assemblies Service Manual, Model 8 and Model 25/32; OEM P/N: 181812-S5
AP_TYAQW6E88FS5VX1KAUM5I2
Front Panel Overlay, 1600VI, 100V/120V
AP_XFIR31OT1Y25GZ9JOS3YDU
Front Panel Overlay, 1600VI, 230/240V
AP_UYQR02G49JGF58MAA0EIJN
Rear Rating/Serial Label, 1600VI, 100V
AP_4HAB5OV6SQB6HAYJ7TDUCU
Rear Rating/Serial Label, 1600VI, 120V
AP_PTI1XN6X3V9832S4FWRT58
Rear Rating/Serial Label, 1600VI, 230/240V
AP_5XMPN70FHCVIIYG7SEH05Y
Safety Warning Label, Rear Panel
AP_43ALAI3SLK8ACAURWHFXEF
Bose Logo/Model Identification Label
AP_7623BRPWPY2A91BESQ9ORM
Serial Number Label
AP_31C4Z4XSO231ONV1U9TDUS
Date-of-Manufacture Label
AP_ZLHAEOYGC3DNSOIDV5UDD0
Grounding Label
AP_ZBOI9U5FBYZI1E313YOFSR
Wire Wrap, Internal Harness
AP_SVQA9YEH4WJUSHGUM1UDEG
Heat-Sink Compound, Service Tube
AP_1CSZG239HC8H8KBPHD3OIB
ESD Protective Bag, PCB Service
AP_UCLYTX5GRCC1BYQV0VXK99
Rack Mount Screw Kit
AP_P0B9IO8AJH20NFQD2LHJOL
Rack Mount Washer Kit
AP_ZE3SLRH3O1TBMOHD5UEFFX
Power Cord Retaining Sleeve
AP_WT1KHJQSWNVW3ZYRUWULUR
Shipping Carton Closure Tape
AP_M96738AJKSDD22P2FHUP65
Protective Polyethylene Sheet
AP_OVMQL8331S28EBT5ZXHN02
Service Calibration/Test Cable Set
AP_RL5TYHMCBB3EV70DT23NPB
Service Dummy Load Adapter
AP_6LH4236YBN4FXCF0DGJSRL
Service Bias Adjustment Tool
AP_E1DRS89G9J5X4CJV500YS2
Warranty/Registration Document
Repair, service & parts, for your Bose 1600 Power Amplifier
- 1 Repairs are performed on a best-effort basis. Acme Revival utilizes a network of sophisticated technicians and engineers with diverse service offerings; despite this, factors that influence the repair outcome may ultimately prove unsuccessful. Acme Revival makes no claim that it can, guarantee a repair before your device is sent in for diagnostic evaluation; even then, repair and diagnostic work are not mutually exclusive. Despite well-intentioned quoting, repairs may still prove unsuccessful.
- 2 Parts known to Acme Revival via Acme’s Neural Network and documented discovery. These parts may not represent OEM cataloging nor does Acme Revival guarantee display accuracy. Always check with Acme’s Help Desk to ensure availability and accuracy. Parts may not be in new condition, may be unavailable, discontinued, or not offered for independent sale.
