Most Recent Repair Requests:
2 (Known) Parts List:
AP_74E3YZH9CVKK38UT74SWQI
HUMPHREY FDT VISUAL FIELD INSTRUMENT COMPLETE ASSEMBLY
AP_BMG9D7U1FL2GURZQFD2WW9
HUMPHREY FDT 710 SERIES 115 V VISUAL FIELD INSTRUMENT
AP_4XXMKNTDG4DWEMEJKXKIH1
HUMPHREY FDT 710 SERIES 230 V VISUAL FIELD INSTRUMENT
AP_ZGJROPLYHTRXVRKDJYA93W
CHASSIS/MONITOR ASSEMBLY
AP_MUWF6ARB555N0C6Z1OIN88
PCB ASSY,MCU; OEM P/N: 112037-504
AP_34NZNWJKHG6DMV2ITO1PFF
MONITOR ASSY; OEM P/N: 112041-502
AP_0I1B3KC6X3K1AO60W1D3ET
MONITOR ASSY; OEM P/N: 112041-503
AP_HTD84IR2B0WN5OIN9KDTBS
LCD MODULE; OEM P/N: 112091-1T
AP_N3079O1SKLRYDWKG3KBTPX
LCD MODULE; OEM P/N: 112091-2
AP_T5JM0GFX5WWR5WPT0ZV29F
FDT - VIEWFINDER™ SOFTWARE KIT; OEM P/N: 0000001272153
AP_A2Z9CRHM7YUZ2XQSKI1YGX
BASE PLATE ASSY; OEM P/N: 112002-1
AP_KN8DOAOI8TRCAJHT4S4GE3
BASE PLATE ASSY; OEM P/N: 112002-2
AP_Z43TX0PHMTB4RVOTPQSWF3
TRANSFORMER (120V/230V ISOLAT); OEM P/N: 112006-1
AP_5ISBIZLVI3NBGN6LDCPA41
TRANSFORMER; OEM P/N: 112006-2
AP_DJLWE94M82NZAUWFQ0UVBF
THERMAL PRINTER, 2; OEM P/N: 112017
AP_VCL6EZI44FSN6X5JVXTXXD
PCB ASSY, LIGHT METER; OEM P/N: 112076-501
AP_F65FKIL6WCXG7CKTF8U3V3
PCB ASSY, LIGHT METER; OEM P/N: 112141-502
AP_D2WRIGUFLJRXK1X9TK422C
PCB ASSY, VPS; OEM P/N: 112079-501
AP_0S3SKUX0IXJ1MWA9FIOX7C
PCB ASSY, VPS; OEM P/N: 112142-501
AP_5KJYMPSFGQG98F31SF7O2V
POWER ENTRY MODULE; OEM P/N: 112005
AP_PWS5LO2O0XK8AIAV3YO1CE
PRB ASSEMBLY (BLACK); OEM P/N: 112050-502
AP_WX93RWEI1CKWDC2BJQWND1
FDT - PATIENT RESPONSE BUTTON; OEM P/N: 0000001045678
AP_6ZKRLVJHSXMZFBVFGU81M1
HOUSING,REAR, PRINTED; OEM P/N: 112025-505
AP_MLYYG0QQNGTSB6L9HQJWVX
HOUSING,REAR, PRINTED; OEM P/N: 112025-505R
AP_57SAL63ALN4CHJONK9PO1C
HOUSING,BASE; OEM P/N: 112003-2
AP_SMF7WF9SEW7UKCB8GF1EZZ
HOUSING, FRONT LEFT; OEM P/N: 112049-3
AP_CLR7ZXXU3WV2WSDB48XCTH
HOUSING, FRONT RIGHT; OEM P/N: 112048-3
AP_A9HND1NXD0MND9F93KB9O8
HOUSING, REAR RIGHT; OEM P/N: 112046-2
AP_E6LLLWM6AKWMJBGTUM4LTC
HOUSING, REAR LEFT; OEM P/N: 112047-2
AP_JKWA5QB6HAICMWAOCOJFLD
HSG,FRONT COVER,PRINTED; OEM P/N: 112024-4
AP_6XOPQBF3E8X6YQ2W5S0IBW
HSG, PAPER DOOR,PRINTED; OEM P/N: 112027-4
AP_YNJ2J57W9BMQKNND3T0V8H
FRONT HSG BACKPLATE W/ PEMS; OEM P/N: 112072-2
AP_WTRR4XGA2WTL5OZ6FLXJDZ
UPPER SHELF W/ PEMS; OEM P/N: 112063
AP_D6K0EYKDAHH1OW2H5V3LG8
PRINTER SHELF W/ PEMS; OEM P/N: 112026
AP_B6UXTFQKC4Q1I6RBY770BM
VISOR BACKPLATE ASSY; OEM P/N: 112039-1
AP_R36I785LMR3JZESGGCNQ7L
FDT - COMPUTER INTERFACE CABLE; OEM P/N: 0000001272743
AP_KIGG2X4KVTXY2Z5DUXFS7Z
SHIELDED RIBBON CABLE ASSY; OEM P/N: 112138-501
AP_XV69SB90LUC2FKVZTD5G7A
LCD CABLE ASSY (40PSN); OEM P/N: 112044-2
AP_9FBB8PE2RMVI6MNW9LWR9D
RIBBON CABLE ASSY, PRN (26PSN); OEM P/N: 112044-1
AP_QVZ34FHQ1LQJPO4QWY1L8J
FLEX CABLE W/ RINGS; OEM P/N: 112094
AP_I7IY9U22RBZWADOODJPW71
JUMPER ASSY RS232; OEM P/N: 112140-1
AP_QSSHIAY6BDCHPZ89TYXQMX
PRB, WIRE ASSY; OEM P/N: 112101-1
AP_VSXVVPYKFVVZZB76AJ8MGK
PRB, WIRE ASSY; OEM P/N: 112143-2
AP_TST333TK7RN9CY9KTXY1YT
WIRE ASSY,10.5; OEM P/N: 112085-2
AP_1OL8U91RSHR34CES3VOSP7
WIRE ASSY, 4.25; OEM P/N: 112085-1
AP_19G0F0IEWI8I9FUXQ0YVUQ
COMPUTER INTERFACE NULL-MODEM RS-232 CABLE
AP_X8EKREBISU3OUDVK6OZGMG
VIEWFINDER SOFTWARE CD
AP_WUB9NL0T179ESZ0BMB2CCQ
VIEWFINDER SOFTWARE INSTRUCTIONS
AP_B50B4N0OTI17WY9KJIN6E2
CALIBRATOR AND SOFTWARE FLOPPY DISC; OEM P/N: T15104
AP_6ZO125CFZGU6B3GLQ4SGR3
FACTORY CALIBRATOR CONNECTOR BOARD; OEM P/N: T-15102
AP_R29YHAJG8U8RFHQGK82IDI
SERIAL PORT TESTER; OEM P/N: T15810
AP_4XBEQ8F3JBH03PR7C4BNXB
FDT CALIBRATION FIXTURE
AP_Q4U6AII7JUCX4HMLBRZ42Z
FDT SERVICE TEST CABLE SET
AP_N9RUILBCVKDFNK5WN93QSW
OPTICS TUBE; OEM P/N: 112008-1
AP_KRIHVR5OW1CURV43YXJ9HI
LENS, ACRYLIC; OEM P/N: 112013
AP_3T5Y2URN8U6E3P5XCXVW5P
WINDOW, OPTICS TUBE; OEM P/N: 112011-1
AP_7SJS3BU93YAOWA9SI00Q3M
VISOR; OEM P/N: 112007-1
AP_V48N5KUANM6KUBMK5VE5S3
BROWREST; OEM P/N: 112010-1
AP_OS32YOVJGLXUN7RYU0HYZN
CALIBRATION CAP; OEM P/N: 112078-1
AP_GBS1B2TLS3AABEI0SPXH6E
FDT - CALIBRATION CAP; OEM P/N: 0000001034279
AP_JQQ17LYKS90RGFZULXO7DQ
GUIDE, VISOR; OEM P/N: 112033-1
AP_7KIMW9GR6JY1HBJVUWHGJL
SLIDE BRACKET; OEM P/N: 112031-1
AP_LDE9M01UIAK448VSIFNMJV
ROD, FINISHED; OEM P/N: 112082-2
AP_KEC3YNINB79Z13LNBUA67A
SPRING VISOR; OEM P/N: 112018
AP_Q8Y5DQIHK9N4JWAZVXI03N
VISOR WEAR PAD; OEM P/N: 112081
AP_HME6UQ8U0VBXAO9WLERRTR
NYLINER BEARING; OEM P/N: 106144-5
AP_QIOX2OZ2IT93TCAP66XDO2
FOOT, RUBBER (BLACK); OEM P/N: 112004-2
AP_7ISMKIAIWYF40PBQ3TKU8H
BATTERY COVER PAD; OEM P/N: 236174-1
AP_JK9SM4H5ELJG882FZGELNI
STANDOFF-SCREW MOUNT; OEM P/N: 106127-1
AP_6EX8VUVTZABJF20B8RRYBT
CONNECTOR, PCB TO PCB; OEM P/N: 112086
AP_HTR19K1YNSPMZ3YJVVZIKR
PRB CONNECTOR JACK
AP_T2ELF7GMWRZ5B4IVDTMUX4
FDT - PATIENT RESPONSE BUTTON HOLDER; OEM P/N: 0000001054028
AP_14FUOHHIQED2VG82JYA1N1
LCD BUTTONS; OEM P/N: 112092-1
AP_K7YXF18M6LMPL1A6SDFNU4
OPERATOR CONTROL PANEL OVERLAY
AP_DD1G9QNUELW4DQMYA9JPJ4
OPERATOR LCD CONTRAST BUTTON SET
AP_R0ELFHC6EHZNQ6M51PUBI6
CANCEL/BACKUP BUTTON (GREEN)
AP_KOU440WPMKZCSFOMXN7QN7
OPERATOR BUTTON SET (BLUE)
AP_90RVP8FL9XMB0S4332O8XA
FUSE CARRIER/VOLTAGE SELECTOR
AP_TAD8GV55R2KHR4AFW72U1M
FUSE DRAWER COVER
AP_22BVAC64T6YC8EVLA3ZPGH
POWER SWITCH
AP_3SSEBERCOQPK2K7U955MZ1
VOLTAGE SELECTOR INDICATOR
AP_8ICLKWKJK9GL1CRY343X1P
POWER CORD INLET
AP_3EJS00PGIW6UP1LAAACPPI
FRONT ESD SHIELD; OEM P/N: 112105-2
AP_K0604ZM70YMWECA2326VSM
FRONT EMI SHIELD; OEM P/N: 112133-1
AP_JDSZ2XBRRMOU718XSKI6RM
EMI SHIELD, REAR; OEM P/N: 112122
AP_VODS53FW5W2O9PKQNYNEVC
EMI SHELD, CRT; OEM P/N: 112155
AP_38AYMKM6ZG1ACTZ98II2BR
BASE SHIELD; OEM P/N: 112137
AP_HS7KWP6GWC55V1U2KIJUQG
TOP EMI SHIELD; OEM P/N: 112146
AP_ZTLJKKSVEGA7QGSO61G02P
LCD ESD SHIELD; OEM P/N: 112043-1
AP_9O8TEZCO30Q9ESL12IZSQ8
LCD ESD SHIELD; OEM P/N: 112145
AP_IEH82PQ8OY4JM1C4S7FL88
PRINTER ENCLOSURE; OEM P/N: 112135
AP_6K791M6OI4BTHX92U8LJ9Y
PRINTER ENCLOSURE GASKET; OEM P/N: 112148
AP_39QDT442IYX8KXGVD2TDLW
PRINTER GASKET; OEM P/N: 112147
AP_0U9RAJQN06Q1GZDCYYT38N
MONITOR GASKET; OEM P/N: 112056
AP_1M9QVGCYWER6YTNZOVIH1P
WINDOW,LCD; OEM P/N: 112042-1
AP_3J27A7OUKJU6TZ6PHSBSZT
EDGE PROTECTOR,U CHANNEL 3.14; OEM P/N: 112080-4
AP_9OJEEZYRT5NESR0MG9O8SP
EDGE PROTECTOR; OEM P/N: 112124-1
AP_IV23REHJLE8HNMNKS7JOHE
EDGE PROTECTOR; OEM P/N: 112124-3
AP_BV3WF8CH9ILX0F4ED4DKP3
EDGE PROTECTOR, 4; OEM P/N: 112124-2
AP_F62QLHV3FC4ALPJ7ZVK1I5
RIBBON CABLE CLAMP; OEM P/N: 112077
AP_C8OKWS8ZRMJOXC2T504X7F
CABLE CLAMP; OEM P/N: 112077-2
AP_YH6MR3SVGJ2N6GV3ONSJ74
WIRECLIP; OEM P/N: 112075
AP_5OK018HB77E46XGP094SO6
CLIP; OEM P/N: 112121
AP_5EWJ9F8G4F4TZV34H06CKV
TIE WRAP; OEM P/N: 761077-1
AP_ADM6HWT3W5NZTV3LDHZKNY
COPPER TAPE; OEM P/N: 112151
AP_IUU8BH4TXZKYUNTQXCA194
FOAM, BLOCK; OEM P/N: 112149
AP_IHHFUUXLNG036R1DT3AQFH
FOAM, STRIP; OEM P/N: 112150
AP_TRDBGG3ZFAJTGQHKBW44AE
FOAM TAPE, LENS; OEM P/N: 112110-2
AP_GRSMM56RWK2ARK773QS5QD
FOAM TAPE OPTICS TUBE WINDOW; OEM P/N: 112110-1
AP_W334X4N8URLH1W067YVH2Y
FOAM, PAPER ROLL; OEM P/N: 112130
AP_UH4PLA3BRCEP2WG6OXDJ5F
FDT - PRINTER PAPER (BOX OF 5); OEM P/N: 2660021101300
AP_OBSG42UWYCL0WUFPROKIDV
THERMAL PAPER ROLL, 2; OEM P/N: 112019
AP_QXZEXWSIFRZG7O2DKS0I6Q
EXTRA ROLL OF PAPER
AP_30M5XOVYRFKK5QB50M4J4H
FUSE - TYPE T .400A 250V (2 REQUIRED); OEM P/N: 2660021131921
AP_8FFRM3T0M9IGXGHXWN7ONF
FUSE, 160 MA; OEM P/N: 236706-3109
AP_TOPUTKD2P29L5179NNJZ0X
FUSE- 315 MA; OEM P/N: 236706-3112
AP_PWZ5X759XUAXW8PGXRJ6R5
POWER CORD - USA, JAPAN, CANADA; OEM P/N: 2660100022511
AP_X1L2Q27OJFF1B53BL71T12
POWER CORD - EUROPE; OEM P/N: 0000001145999
AP_YK5DO8F1BWIV4D5980R0LM
POWER CORD - UNITED KINGDOM; OEM P/N: 2660021133168
AP_UVNTQXRELTTGFPPCODE1VY
POWER CORD - AUSTRALIA; OEM P/N: 2660021131890
AP_3SGAHSZXU6KOHX0UGRM5RN
POWER CORD, DETACH.(DOM/JAPAN); OEM P/N: 761076-0
AP_T8MKVZ3G3S1HNGIRTJTRL5
POWER CORD, DETACH. (EUROPEAN); OEM P/N: 761076-2
AP_3UQ61GJOG1MGS0XXLMDW1T
POWER CORD, DETACH. (UK); OEM P/N: 761076-4
AP_DPYX4DUIB00IDZ5Z8MHRT9
POWER CORD, DETACH. (AUSTRALIA); OEM P/N: 761076-6
AP_3Y3YYFN2HM1JHWTKLXGFGK
FDT - DUST COVER; OEM P/N: 0000001096628
AP_DLV7959WQ3HYJGHZIHUTRC
BOX ASSEMBLY; OEM P/N: 112113-504
AP_C8NY6NZ4BA2BXURPP8YT60
ANTISTATIC POLY BAG(30X36)PINK; OEM P/N: M11526
AP_LI6UZLYWBVOKSOVK6BGJO6
DESICCANT BAG; OEM P/N: 112131
AP_57QH3QWFCHC25R0W3Y8I4K
SHIPPING CARTON OUTER
AP_3J7A4X7CD6XRAJ8S5YKRSS
SHIPPING FOAM INSERT, TOP
AP_CKPHM03435WZAQ5W3BIXAH
SHIPPING FOAM INSERT, BOTTOM
AP_U9PEYHRZH6THCJZFZFJ79D
PROTECTIVE PLASTIC BAG
AP_BOQYGCABX0JAHAC9RYI81A
PACKING TAPE
AP_CE4IKIOYRRFR5WRKAKCUF1
ACCESSORY PACK BAG
AP_P1DAZJI2QXL974AO234PHM
PAPER ROLL SHIPPING WEDGE
AP_WQ2HL6136DIES49UYTTVRZ
FDT - USER DOCUMENTATION DISK; OEM P/N: 2660021134021
AP_A3BVLIOBT84R1LV9S2MTZC
REPAIR MANUAL; OEM P/N: 112120
AP_HA35144HI3UXRZS011BFWQ
FDT - USER'S GUIDE, ENGLISH; OEM P/N: 112098
AP_MLIURFC44P1LSN65V373RK
OPERATING INSTRUCTIONS,; OEM P/N: 112098C
AP_GS0AO9H3D8GBHHO3S08DPW
FDT USER'S GUIDE, FRENCH; OEM P/N: 112098FR
AP_XK2Z6MWTGVH9AEN0TL6L7W
FDT USER'S GUIDE, GERMAN; OEM P/N: 112098GR
AP_EXXEDX4DFCJB0UE5TURID7
FDT USER'S GUIDE, ITALIAN; OEM P/N: 112098IT
AP_C2F1LR9JWIBG3K0O6XR45P
FDT USER'S GUIDE, SPANISH; OEM P/N: 112098SP
AP_C4T3PJVKZ3W0SZUPRCY429
FDT - QUICK REFERENCE,ENGLISH; OEM P/N: 112136
AP_D7NKN1SWI94YD8FKTGULSO
QUICK REFERENCE GUIDE, FRENCH
AP_X6YSK6IAFGIV3V08WL0XTD
QUICK REFERENCE GUIDE, GERMAN
AP_Q6IV0CYQBT3286KO0ZOW09
QUICK REFERENCE GUIDE, ITALIAN
AP_3VJ7FJWOWAL731PPRITFU1
QUICK REFERENCE GUIDE, SPANISH
AP_K85ZXFDZBPMKZ57USLGLWN
FDT, REGISTRATION CARD,ENGLISH; OEM P/N: 112132
AP_667Z5LTSA2EF3RXTKY2NYR
LABEL,MODEL DOMESTIC; OEM P/N: 112057-4
AP_1N9Y8OIXWGYC9RWJW4YDYK
LABEL,MODEL INTL; OEM P/N: 112057-3
AP_E1N25RFO289BN8NEAFXH0Y
PARTS LABEL; OEM P/N: M11478
AP_LHFRXAKVGJ6TP0K5SUFKKD
LABEL, CONNECTOR ID; OEM P/N: 112067-1
AP_NA48P5EL9WI851YQMLURKU
GROUND LABEL; OEM P/N: 488383
AP_TYAWS228H9MYI7J82MQ5J9
LABEL, FUSE/READ MANUAL; OEM P/N: 112064-2
AP_IJFCM91D37QFALIOU184QF
LABEL, PRB MODEL; OEM P/N: 112065-2
AP_U0MVS09QTG1UVU5KWTFS8S
LABEL, OPTICS TUBE; OEM P/N: 112074
AP_J13WCLVOJBXGLN3CVO8ZIT
LABEL, PAPER LOADING INSTR; OEM P/N: 112068-2
AP_ASEZTL0KMXXQ2898EVUJ9L
LABEL, FRONT COVER LOGO G; OEM P/N: 112129-1
AP_YWP4KMIIL1ATK0S82TC7C3
LABEL, BACKGRND DEBUG CONN; OEM P/N: 112066
AP_CPPDNR5URPAMCKRU69UGZD
LABEL, VPS REFLECTIVE; OEM P/N: 112061-1
AP_2WI018VHYXY7IE3PYH9YP0
CALIBRATION/SOFTWARE LOADING PORT BLANK LABEL
AP_OH06VPF3SSGDWNV7D7J4QK
SERIAL NUMBER LABEL
AP_TW3SE2LTJKMRA3FMDTGE3Q
EU AUTHORIZED REPRESENTATIVE LABEL
AP_8YQBO2BDHL3IJ3AXG9V9JW
UL/CSA/IEC COMPLIANCE LABEL
AP_XUUKSG8KSS4FXFMCA062W5
WARNING/CAUTION LABEL SET
AP_QB1L11EI85G7GZTMZQU5R8
MYLAR WASHER; OEM P/N: 106103-43
AP_UHTSZUNBGZT6ZG8RLVHRLD
WASHER, FLAT; OEM P/N: 106103-6
AP_74LNDQ8EV0UA05J1CVFHET
NUT,8-32 EXTLOCK; OEM P/N: 106137-2
AP_I4JVBPJJQ82RETLHFXG72V
NUT 6-32 EXTLOCK; OEM P/N: 106137-7
AP_E8JO89XX041VTOADPFC1MA
#6 LOCKWASHER-EXTERNAL TOOTH; OEM P/N: 745147
AP_ABSJT37HJWN5JGYR6BXYIX
#4 LOCKWASHER,HEL; OEM P/N: 106105-3
AP_6ECFXA6YZG5AJTV8PS08BR
6-32 W/EXT WASHER; OEM P/N: 106140-5
AP_IM659SAZEWMJ17NU173SXZ
8-32 W/EXT WASHER; OEM P/N: 106140-9
AP_JXRKFL4L8FIWHCUOIQM6BG
SCREW, BUTTON HS SOCKET G; OEM P/N: 106138-6
AP_ISU78UHZ8MKXCAB207DRGG
PHPS 8-32 X .750; OEM P/N: 106100-51
AP_2UZD5ULQJAL9CB5RRZ9CHT
#4 X.250 LG PPHS SELF TPG; OEM P/N: 106124-4
AP_NB7HMCX2Y7GVYNYW0P5F16
SCREW #6 X .375; OEM P/N: 106124-30
AP_YH7FG069PJHG8RU5MW71IO
4-40 X.25 SCREW; OEM P/N: 106100-42
AP_GL6IVI0YHOQ2L828AG9U6Q
PHPS 8-32 X.281; OEM P/N: 106100-12
AP_46WNS1QURPEV8JL4D4Q6A7
SCREW,M3 PHPS METRIC; OEM P/N: 711776
AP_GHQ90C2O8PZZPF7ITG3E17
6-32 X .125 PHILLIPS,STL; OEM P/N: 106100-50
AP_Q7C10FZWTGUA5ABBPS7H3F
#4 X.250 LG PPHS SELF TPG; OEM P/N: 106124-31
AP_S7C8ZFPXULS5KDKX71VDZW
FHPHPS 6X32X.250 LG; OEM P/N: 106102-27
AP_KRDTB0OKCFA60K2N180FJK
PHPS 6-32 X 5/16; OEM P/N: 483017
AP_4FYJM6DKO5ZMPPO37OYR0L
SCREW .500 AB PAN PHILLIPS; OEM P/N: 106124-36
AP_C6KQJA224F6MLDPKRVDKO9
.344 HEX SOCKET ST BLACK ANODI; OEM P/N: 106119-34
AP_YNL8IM29AG5NPCGYHHWH4M
PHPS 8-32 X .500; OEM P/N: 106100-52
Repair, service & parts, for your Zeiss Humphrey FDT 710
- 1 Repairs are performed on a best-effort basis. Acme Revival utilizes a network of sophisticated technicians and engineers with diverse service offerings; despite this, factors that influence the repair outcome may ultimately prove unsuccessful. Acme Revival makes no claim that it can, guarantee a repair before your device is sent in for diagnostic evaluation; even then, repair and diagnostic work are not mutually exclusive. Despite well-intentioned quoting, repairs may still prove unsuccessful.
- 2 Parts known to Acme Revival via Acme’s Neural Network and documented discovery. These parts may not represent OEM cataloging nor does Acme Revival guarantee display accuracy. Always check with Acme’s Help Desk to ensure availability and accuracy. Parts may not be in new condition, may be unavailable, discontinued, or not offered for independent sale.
